Lennox 80MGF3/4-100

Page 7
FIGURE 1
80MGF PARTS IDENTIFICATION
and ORIENTATION
VENT ADAPTER
CABINET TOP
80MGF
CABINET
CABINET
BOTTOM
HEAT EXCHANGER
ASSEMBLY
BURNER
ASSEMBLY
BLOWER ASSEMBLY
COMBUSTION AIR
BLOWER
FLUE BOX
SECONDARY
LIMITS
FRONT ACCESS
PANEL
DOOR INTERLOCK SWITCH
CONTROL
BOARD
TRANSFORMER
PRESSURE
SWITCH
NOx
TURBULATOR
PRIMARY
LIMIT
FIGURE 2
HEATING COMPONENTS (shown in horizontal position)
HEAT EXCHANGER
COMBUSTION AIR BLOWER
MANIFOLD
ROLLOUT SWITCH (2)
COMBUSTION AIR
PROVE SWITCH
GAS VALVE
BURNERS
COLLECTOR
PRIMARY LIMIT
Front
Right
Top
Bottom
Left
Back
