Page 37 - Application Guide 04-2003 / Rooftop BALTIC Series - Page 37
BCK = Cooling only rooftop BHK = Heat pump rooftop
P Fan motor power in kW
Table 5.5
040 STD 100 150 200 250 300
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
5800 K1 1*0.8 551 K3 1*1.1 625 K3 1*1.1 696 K4 1*1.5 762 K5 1*1.5 825
6267 K2 1*0.8 571 K3 1*1.1 642 K3 1*1.1 709 K4 1*1.5 772 K5 1*1.5 833
6733 K11 1*1.1 592 K3 1*1.1 659 K4 1*1.5 723 K4 1*1.5 784 K9 1*2.2 843
7200 K3 1*1.1 614 K8 1*1.5 678 K4 1*1.5 739 K5 1*1.5 798 K9 1*2.2 855
7667 K3 1*1.1 638 K8 1*1.5 698 K4 1*1.5 757 K9 1*2.2 813 K9 1*2.2 868
8133 K8 1*1.5 662 K4 1*1.5 720 K13 1*2.2 776 K9 1*2.2 830 K9 1*2.2 882
8600 K8 1*1.5 687 K13 1*2.2 742 K9 1*2.2 795 K9 1*2.2 847 K12 1*3.0 898
040 STD 350 400 450 500
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM
5800 K5 1*1.5 884 K6 1*2.2 941 K7 1*2.2 996 K7 1*2.2 1048
6267 K6 1*2.2 891 K6 1*2.2 946 K7 1*2.2 999 K7 1*2.2 1051
6733 K6 1*2.2 899 K6 1*2.2 953 K7 1*2.2 1005 K10 1*3.0 1055
7200 K6 1*2.2 909 K6 1*2.2 961 K10 1*3.0 1012 K10 1*3.0 1060
7667 K6 1*2.2 920 K12 1*3.0 971 K10 1*3.0 1020 K10 1*3.0 1068
8133 K12 1*3.0 933 K12 1*3.0 982 K10 1*3.0 1030 K10 1*3.0 1076
8600 K12 1*3.0 947 K12 1*3.0 995 K10 1*3.0 1041 K14 1*4.0 1086
Table 5.6
045 STD 100 150 200 250 300
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
6500 K1 1*0.8 577 K2 1*1.1 647 K2 1*1.1 712 K3 1*1.5 775 K4 1*2.2 835
7033 K2 1*1.1 602 K2 1*1.1 667 K3 1*1.5 730 K3 1*1.5 789 K4 1*2.2 847
7567 K2 1*1.1 628 K8 1*1.5 690 K3 1*1.5 749 K4 1*2.2 806 K4 1*2.2 861
8100 K8 1*1.5 655 K3 1*1.5 713 K10 1*2.2 770 K4 1*2.2 824 K4 1*2.2 877
8633 K8 1*1.5 683 K10 1*2.2 738 K10 1*2.2 792 K4 1*2.2 844 K12 1*3.0 894
9167 K10 1*2.2 712 K10 1*2.2 764 K4 1*2.2 815 K12 1*3.0 865 K9 1*3.0 913
9700 K10 1*2.2 741 K10 1*2.2 791 K12 1*3.0 840 K12 1*3.0 887 K9 1*3.0 934
045 STD 350 400 450 500
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM
6500 K5 1*2.2 892 K5 1*2.2 946 K5 1*2.2 999 K6 1*3.0 1050
7033 K5 1*2.2 902 K5 1*2.2 955 K6 1*3.0 1006 K6 1*3.0 1055
7567 K5 1*2.2 914 K9 1*3.0 965 K6 1*3.0 1015 K6 1*3.0 1063
8100 K9 1*3.0 928 K9 1*3.0 977 K6 1*3.0 1025 K6 1*3.0 1072
8633 K9 1*3.0 943 K9 1*3.0 991 K6 1*3.0 1037 K11 1*4.0 1083
9167 K9 1*3.0 961 K6 1*3.0 1007 K11 1*4.0 1051 K11 1*4.0 1095
9700 K13 1*4.0 979 K11 1*4.0 1024 K11 1*4.0 1067 K11 1*4.0 1109
PERFORMANCES evaporator fan
Highlighted value correspond to nominal conditions
