Page 38 - Application Guide 04-2003 / Rooftop BALTIC Series
P Fan motor power in kW
BCK = Cooling only rooftop BHK = Heat pump rooftop
Table 5.7
050 STD 100 150 200 250 300
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
7200 K1 1*1.1 602 K2 1*1.5 666 K3 1*1.5 728 K3 1*1.5 787 K4 1*2.2 844
7800 K2 1*1.5 631 K2 1*1.5 691 K3 1*1.5 750 K4 1*2.2 806 K4 1*2.2 860
8400 K2 1*1.5 661 K8 1*2.2 718 K8 1*2.2 773 K4 1*2.2 826 K4 1*2.2 878
9000 K8 1*2.2 692 K8 1*2.2 746 K4 1*2.2 798 K4 1*2.2 849 K10 1*3.0 898
9600 K8 1*2.2 724 K8 1*2.2 775 K10 1*3.0 824 K10 1*3.0 873 K6 1*3.0 920
10200 K8 1*2.2 757 K10 1*3.0 805 K10 1*3.0 852 K10 1*3.0 898 K11 1*4.0 943
10800 K10 1*3.0 790 K10 1*3.0 836 K10 1*3.0 881 K11 1*4.0 925 K11 1*4.0 968
050 STD 350 400 450 500
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM
7200 K5 1*2.2 899 K5 1*2.2 951 K6 1*3.0 1002 K7 1*3.0 1051
7800 K5 1*2.2 912 K6 1*3.0 963 K7 1*3.0 1012 K7 1*3.0 1060
8400 K6 1*3.0 928 K6 1*3.0 977 K7 1*3.0 1024 K9 1*4.0 1070
9000 K6 1*3.0 946 K6 1*3.0 993 K9 1*4.0 1038 K9 1*4.0 1083
9600 K6 1*3.0 966 K9 1*4.0 1011 K9 1*4.0 1055 K9 1*4.0 1097
10200 K11 1*4.0 987 K9 1*4.0 1030 K9 1*4.0 1073 K12 1*5.5 1114
10800 K9 1*4.0 1010 K9 1*4.0 1052 K14 1*5.5 1092 K12 1*5.5 1132
PERFORMANCES evaporator fan
Highlighted value correspond to nominal conditions
