Page 39 - Application Guide 04-2003 / Rooftop BALTIC Series - Page 39
BGK = Gas fired rooftop BDK = Dual fuel rooftop (heat pump + gas fired)
Table 5.8
020 GAS 100 150 200 250 300 350 400
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
2900 K1 1*0.8 746 K1 1*0.8 826 K2 1*0.8 902 K2 1*0.8 974 K3 1*0.8 1043 K3 1*0.8 1108 K4 1*1.1 1170
3133 K1 1*0.8 780 K1 1*0.8 856 K2 1*0.8 928 K2 1*0.8 997 K3 1*0.8 1063 K5 1*1.1 1126 K4 1*1.1 1187
3367 K1 1*0.8 816 K2 1*0.8 888 K2 1*0.8 956 K3 1*0.8 1023 K5 1*1.1 1086 K5 1*1.1 1147 K4 1*1.1 1206
3600 K1 1*0.8 852 K2 1*0.8 921 K2 1*0.8 986 K5 1*1.1 1049 K5 1*1.1 1110 K4 1*1.1 1169 K4 1*1.1 1226
3833 K2 1*0.8 890 K7 1*1.1 955 K5 1*1.1 1017 K5 1*1.1 1078 K5 1*1.1 1137 K4 1*1.1 1193 K6 1*1.5 1248
4067 K7 1*1.1 928 K5 1*1.1 990 K5 1*1.1 1050 K5 1*1.1 1108 K6 1*1.5 1164 K6 1*1.5 1219 K6 1*1.5 1272
4300 K5 1*1.1 968 K5 1*1.1 1027 K5 1*1.1 1084 K8 1*1.5 1139 K6 1*1.5 1194 K6 1*1.5 1247 K6 1*1.5 1298
Table 5.9
025 GAS 100 150 200 250 300 350 400
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
3600 K1 1*0.8 834 K1 1*0.8 903 K1 1*0.8 969 K2 1*1.1 1033 K2 1*1.1 1095 K2 1*1.1 1154 K3 1*2.2 1211
3900 K1 1*0.8 881 K4 1*1.1 945 K4 1*1.1 1008 K2 1*1.1 1068 K2 1*1.1 1127 K3 1*2.2 1183 K5 1*1.5 1238
4200 K4 1*1.1 929 K4 1*1.1 989 K2 1*1.1 1048 K2 1*1.1 1106 K5 1*1.5 1161 K5 1*1.5 1216 K5 1*1.5 1268
4500 K4 1*1.1 978 K2 1*1.1 1035 K6 1*1.5 1091 K6 1*1.5 1145 K5 1*1.5 1198 K5 1*1.5 1250 K7 1*2.2 1301
4800 K6 1*1.5 1028 K6 1*1.5 1082 K6 1*1.5 1135 K5 1*1.5 1187 K7 1*2.2 1237 K7 1*2.2 1287 K7 1*2.2 1335
5100 K6 1*1.5 1079 K6 1*1.5 1130 K3 1*2.2 1181 K7 1*2.2 1230 K7 1*2.2 1278 K7 1*2.2 1325 K8 1*3.0 1372
5400 K3 1*2.2 1131 K3 1*2.2 1180 K7 1*2.2 1227 K7 1*2.2 1274 K7 1*2.2 1320 K8 1*3.0 1365 K8 1*3.0 1410
Table 5.10
030 GAS 100 150 200 250 300 350 400
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
4300 K1 1*0.8 641 K2 1*1.1 706 K2 1*1.1 771 K3 1*1.1 834 K3 1*1.1 895 K4 1*1.5 954 K4 1*1.5 1011
4667 K2 1*1.1 674 K2 1*1.1 734 K3 1*1.1 794 K3 1*1.1 854 K4 1*1.5 911 K4 1*1.5 968 K4 1*1.5 1022
5033 K2 1*1.1 708 K2 1*1.1 765 K3 1*1.1 821 K5 1*1.5 876 K4 1*1.5 931 K4 1*1.5 984 K6 1*2.2 1036
5400 K2 1*1.1 744 K3 1*1.1 796 K5 1*1.5 849 K4 1*1.5 901 K4 1*1.5 952 K6 1*2.2 1003 K7 1*2.2 1053
5767 K5 1*1.5 781 K5 1*1.5 830 K5 1*1.5 879 K8 1*2.2 928 K6 1*2.2 976 K6 1*2.2 1025 K7 1*2.2 1072
6133 K5 1*1.5 818 K5 1*1.5 864 K8 1*2.2 911 K8 1*2.2 957 K6 1*2.2 1003 K7 1*2.2 1048 K7 1*2.2 1093
6500 K8 1*2.2 856 K8 1*2.2 900 K8 1*2.2 944 K6 1*2.2 987 K6 1*2.2 1031 K9 1*3.0 1074 K10 1*3.0 1117
Table 5.11
035 GAS 100 150 200 250 300 350 400
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
5000 K1 1*1.1 698 K1 1*1.1 755 K1 1*1.1 811 K2 1*1.5 867 K3 1*1.5 922 K3 1*1.5 976 K4 1*2.2 1029
5433 K1 1*1.1 740 K1 1*1.1 792 K2 1*1.5 844 K3 1*1.5 896 K3 1*1.5 947 K4 1*2.2 998 K4 1*2.2 1048
5867 K2 1*1.5 783 K2 1*1.5 831 K3 1*1.5 880 K5 1*2.2 928 K4 1*2.2 976 K4 1*2.2 1023 K4 1*2.2 1070
6300 K2 1*1.5 827 K5 1*2.2 872 K5 1*2.2 917 K5 1*2.2 962 K4 1*2.2 1007 K4 1*2.2 1051 K6 1*3.0 1095
6733 K5 1*2.2 871 K5 1*2.2 914 K5 1*2.2 956 K4 1*2.2 998 K6 1*3.0 1040 K6 1*3.0 1082 K8 1*3.0 1124
7167 K5 1*2.2 917 K5 1*2.2 957 K9 1*3.0 996 K6 1*3.0 1036 K6 1*3.0 1076 K8 1*3.0 1115 K8 1*3.0 1154
7600 K9 1*3.0 963 K9 1*3.0 1001 K6 1*3.0 1038 K6 1*3.0 1075 K8 1*3.0 1113 K10 1*4.0 1150 K10 1*4.0 1187
P Fan motor power in kW
PERFORMANCES evaporator fan
Highlighted value correspond to nominal conditions
