Lennox BALTIC Series User Manual

Page 40 - Application Guide 04-2003 / Rooftop BALTIC Series
BGK = Gas fired rooftop BDK = Dual fuel rooftop (heat pump + gas fired)
P Fan motor power in kW
Table 5.12
040 GAS 100 150 200 250 300
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
5800 K1 1*1.1 671 K2 1*1.1 739 K3 1*1.5 803 K3 1*1.5 864 K4 1*2.2 921
6267 K2 1*1.1 703 K3 1*1.5 767 K3 1*1.5 828 K4 1*2.2 886 K4 1*2.2 942
6733 K9 1*1.5 737 K3 1*1.5 797 K8 1*2.2 855 K4 1*2.2 911 K4 1*2.2 964
7200 K3 1*1.5 771 K8 1*2.2 829 K8 1*2.2 884 K4 1*2.2 937 K10 1*3.0 988
7667 K8 1*2.2 806 K8 1*2.2 861 K4 1*2.2 914 K10 1*3.0 965 K7 1*3.0 1014
8133 K8 1*2.2 842 K4 1*2.2 894 K10 1*3.0 945 K10 1*3.0 993 K7 1*3.0 1041
8600 K8 1*2.2 879 K10 1*3.0 928 K10 1*3.0 976 K7 1*3.0 1023 K11 1*4.0 1069
040 GAS 350 400 450 500
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM
5800 K5 1*2.2 977 K5 1*2.2 1030 K5 1*2.2 1081 K6 1*3.0 1130
6267 K5 1*2.2 995 K5 1*2.2 1047 K7 1*3.0 1096 K6 1*3.0 1144
6733 K5 1*2.2 1016 K7 1*3.0 1065 K6 1*3.0 1113 K6 1*3.0 1160
7200 K7 1*3.0 1038 K7 1*3.0 1086 K6 1*3.0 1133 K11 1*4.0 1178
7667 K7 1*3.0 1062 K6 1*3.0 1108 K11 1*4.0 1153 K11 1*4.0 1197
8133 K11 1*4.0 1087 K11 1*4.0 1132 K11 1*4.0 1175 No kit
8600 K11 1*4.0 1113 K11 1*4.0 1157 K11 1*4.0 1199 No kit
Table 5.13
045 GAS 100 150 200 250 300
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
6500 K1 1*1.5 717 K1 1*1.5 779 K2 1*2.2 838 K3 1*2.2 895 K3 1*2.2 950
7033 K1 1*1.5 755 K1 1*1.5 814 K2 1*2.2 870 K3 1*2.2 924 K3 1*2.2 976
7567 K2 1*2.2 795 K2 1*2.2 850 K3 1*2.2 903 K3 1*2.2 955 K6 1*3.0 1005
8100 K2 1*2.2 835 K3 1*2.2 887 K6 1*3.0 938 K6 1*3.0 987 K4 1*3.0 1035
8633 K2 1*2.2 877 K6 1*3.0 926 K6 1*3.0 974 K4 1*3.0 1021 K8 1*4.0 1067
9167 K6 1*3.0 919 K6 1*3.0 966 K8 1*4.0 1012 K8 1*4.0 1056 K8 1*4.0 1100
9700 K6 1*3.0 961 K8 1*4.0 1006 K8 1*4.0 1050 K8 1*4.0 1093 K7 1*4.0 1134
045 GAS 350 400 450 500
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM
6500 K3 1*2.2 1002 K4 1*3.0 1053 K5 1*3.0 1102 K5 1*3.0 1149
7033 K4 1*3.0 1027 K4 1*3.0 1075 K5 1*3.0 1123 K5 1*3.0 1168
7567 K4 1*3.0 1053 K4 1*3.0 1100 K7 1*4.0 1145 K7 1*4.0 1190
8100 K4 1*3.0 1081 K7 1*4.0 1126 K7 1*4.0 1170 No kit
8633 K7 1*4.0 1111 K7 1*4.0 1154 K7 1*4.0 1197 No kit
9167 K7 1*4.0 1143 K9 1*5.5 1184 No kit No kit
9700 K9 1*5.5 1175 No kit No kit No kit
PERFORMANCES evaporator fan
Highlighted value correspond to nominal conditions
