Page 41 - Application Guide 04-2003 / Rooftop BALTIC Series - Page 41
P Fan motor power in kW
BGK = Gas fired rooftop BDK = Dual fuel rooftop (heat pump + gas fired)
Table 5.14
050 GAS 100 150 200 250 300
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM Kit P RPM
7200 K1 1*2.2 760 K1 1*2.2 818 K1 1*2.2 874 K2 1*2.2 927 K2 1*2.2 979
7800 K1 1*2.2 804 K1 1*2.2 859 K2 1*2.2 911 K3 1*3.0 962 K4 1*3.0 1011
8400 K1 1*2.2 850 K3 1*3.0 901 K3 1*3.0 950 K3 1*3.0 998 K4 1*3.0 1045
9000 K3 1*3.0 896 K3 1*3.0 944 K3 1*3.0 991 K7 1*4.0 1037 K7 1*4.0 1081
9600 K3 1*3.0 943 K7 1*4.0 989 K7 1*4.0 1033 K7 1*4.0 1076 K6 1*4.0 1119
10200 K7 1*4.0 991 K7 1*4.0 1034 K7 1*4.0 1076 K8 1*5.5 1117 K8 1*5.5 1158
10800 K7 1*4.0 1039 K8 1*5.5 1080 K8 1*5.5 1120 K8 1*5.5 1160 K8 1*5.5 1198
050 GAS 350 400 450 500
Air flow Kit P RPM Kit P RPM Kit P RPM Kit P RPM
7200 K4 1*3.0 1029 K4 1*3.0 1077 K5 1*3.0 1124 K6 1*4.0 1169
7800 K4 1*3.0 1058 K5 1*3.0 1105 K6 1*4.0 1150 K6 1*4.0 1193
8400 K7 1*4.0 1090 K6 1*4.0 1135 K6 1*4.0 1178 No kit
9000 K6 1*4.0 1124 K6 1*4.0 1167 No kit No kit
9600 K8 1*5.5 1160 No kit No kit No kit
10200 K8 1*5.5 1198 No kit No kit No kit
10800 No kit No kit No kit No kit
PERFORMANCES evaporator fan
!The pressure drop difference between Standard Heat and High Heat gas burners being negligeable,
these tables can be used for both.
Highlighted value correspond to nominal conditions
