Lennox BALTIC Series

Page 76 - Application Guide 04-2003 / Rooftop BALTIC Series
2F'
2F
1F
1F' 1F 1F'
1F'
1F
2F'
2F
1F'
1F
2F'
2F
MULTIDIRECTIONAL HORIZONTAL ROOFCURB
035030
BCK
BHK
1F'
Front supply air
2F
2F'
Front return air
1F
Front supply air
WARNING : ONLY ONE OF THE 4 FOLLOWINGS POSSIBILIES :
2F - 1F / 2F - 1F'
2F' - 1F / 2F' - 1F'
Front return air
