Lennox CBX40UHV Series Unit Information

Page 7
CBX40UHV
CBX40UHV-048 and CBX40UHV−060 BLOWER MOTOR WATTS AT +" (Plus) AHC SETTING (Adjust" Jumper at +"
Setting)
AHC JUMPER SPEED
POSITIONS
MOTOR WATTS @ VARIOUS EXTERNAL STATIC PRESSURES − IN. WG.
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
HEAT SPEED
TAP 1 418 478 539 551 599 646 675 704 748
TAP 2 492 540 585 642 684 732 761 797 834
TAP 3 594 645 721 762 811 863 874 918 976
TAP 4 653 713 755 809 861 909 941 974 1028
COOL SPEED
TAP 1 312 342 373 414 443 475 512 558 587
TAP 2 407 459 503 552 591 627 670 718 752
TAP 3 581 646 691 737 792 826 863 900 942
TAP 4 646 695 746 804 873 900 934 976 1032
CBX40UHV-048 and CBX40UHV−060 BLOWER MOTOR WATTS AT NORM" AHC SETTING (Adjust" Jumper at NORM
Setting)
AHC JUMPER SPEED
POSITIONS
MOTOR WATTS @ VARIOUS EXTERNAL STATIC PRESSURES − IN. WG.
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
HEAT SPEED
TAP 1 325 366 404 444 475 520 566 598 636
TAP 2 369 421 465 516 560 587 616 666 717
TAP 3 436 488 540 586 621 671 710 743 789
TAP 4 523 581 636 684 738 789 816 852 894
COOL SPEED
TAP 1 226 259 293 322 350 387 413 446 472
TAP 2 312 355 382 423 450 492 520 570 615
TAP 3 388 421 482 523 564 606 641 695 741
TAP 4 538 599 647 686 718 792 820 853 888
CBX40UHV-048 and CBX40UHV−060 BLOWER MOTOR WATTS AT −" (Minus) AHC SETTING (Adjust" Jumper at −"
Setting)
AHC JUMPER SPEED
POSITIONS
MOTOR WATTS @ VARIOUS EXTERNAL STATIC PRESSURES − IN. WG.
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
HEAT SPEED
TAP 1 271 302 341 368 398 439 473 504 545
TAP 2 286 329 356 393 423 462 504 550 572
TAP 3 327 374 407 455 504 526 563 608 638
TAP 4 355 404 442 496 539 560 602 643 684
COOL SPEED
TAP 1 124 163 180 209 231 271 300 322 357
TAP 2 192 233 252 282 321 356 390 422 449
TAP 3 268 311 336 367 393 432 469 523 538
TAP 4 328 376 420 463 486 536 572 612 657
