ACCESS COVER
REMD16M PARTS ARRANGEMENT
FIGURE 22
REMD16 PARTS ARRANGEMENT
ENTHALPY CONTROL
ACCESS COVER
REMOTE
MOUNTING BASE
DAMPER MOTOR
ENTHALPY CONTROL
DAMPER MOTOR
MIXED AIR
SENSOR CONTROL
MIXED AIR
SENSING BULB
NOTE - Mixed air sensor and
sensing bulb are shown as they
are factory installed in a
REMD16-41. REMD16-65 is simĆ
ilar. Mixed air sensor should be
removed from economizer and
installed in unit blower compartĆ
ment and sensing bulb should
be installed in supply air stream
as shown in figure 26.
OUTDOOR AIR DAMPERS
RETURN AIR DAMPERS
MIXED AIR
SENSOR
NOTE - Mixed air sensor is shown as it
is factory installed in a REMD16M-41.
REMD16M-65 is similar. Mixed air senĆ
sor should be removed from econoĆ
mizer and installed in supply air
stream as shown in figure 26.
