• 78 • CLIMATIC RT_UNITARY-IOM-1508-E
APPENDIX 8
eCLIMATIC Inputs
INPUTS / OUTPUTS CLIMATIC BOARDS
BM J7.DI1 Blower, Status (Switch)
BM J7.DI2 Circuit 1, Compressors, Status (Switch)
BM J7.DI3
Circuit 1, Condenser Fan, Status (Switch)
[Water Condenser] Flow switch (Switch)
BM J7.DI4
[CGBS] [CGBH] Valve 1, Status (Switch)
[ELHS][ELHM][ELHH] Electrical Heaters, Status (Switch)
[HWCS][HWCH] Hot/Cold Water Coil, Antifreeze Sensor (Switch)
BM J25.DI7 Circuit 2, Compressors, Status (Switch)
BM J25.DI8
Circuit 2, Condenser Fan, Status (Switch)
[Water Condenser] Pump, Status (Switch)
BM J26.DI9
[CGBS] [CGBH] Valve 2, Status (Switch)
[ENRE] Pump, Status (Switch)
BM J26.DI10 [DADS] Fire/Smoke Detector (Switch)
BM J2.U1
Return (NTC)
[Small] Room (NTC)
BM J2.U2
Outside (NTC)
[HRMO] Outlet Wheel Recovery (NTC)
BM J2.U3 Supply (NTC)
BM J2.U3 Supply (NTC)
BM J3.U4
Circuit 1, Condensing -1~45b (4~20mA)
[Aqualean] Circuit 1, Discharge 1 (NTC 120)
BM J3.U5
Circuit 1, Evaporating -1~20b (0~5V)
[HWCS][HWCH & Unit w/circuit] Hot/Cold Water Coil, Inlet (NTC)
[no sensor] Circuit 1, Low Pressure switch (Switch)
BM J4.U6
Circuit 2, Condensing -1~45b (4~20mA)
[Water Condenser, Unit 1 Circuit] Water Condenser, Inlet (NTC)
BM J4.U7
Circuit 2, Evaporating -1~20b (0~5V)
[Water Condenser, Unit 1 Circuit] Water Condenser, Outlet (NTC)
[no sensor] Circuit 2, Low Pressure switch (Switch)
BM J5.U8
Circuit 1, Suction (NTC)
[ENRE & Unit w/circuit] Hot/Cold Water Recovery, Inlet (NTC)
BM J5.U9
Filters/Fan 0~500pa (0~5V)
[Aqualean] Water Condenser Pump, Status (Switch)
BM J5.U10
[EPHS][EPHH] Electrical Heaters, Fresh Air, Status (Switch)
[PHMO] Plate Recovery, Switch Air (Switch)
[HWCS][HWCH] Pump, Status (Switch)
BM J26.U11 Circuit 2, Suction (NTC)
BM J26.U12
Room (NTC)
[ADCP] Outside, Humidity 0~100%Hr (4~20mA)
[NSR] Blower Pressure 0~500pa (0~5V)
