Lennox CLIMATIC series User Manual

• 79 •CLIMATIC RT_UNITARY-IOM-1508-E
APPENDIX 8
eCLIMATIC Inputs
INPUTS / OUTPUTS CLIMATIC BOARDS
BE.1 J2.U1 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U2 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U3 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U4 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U5 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U6 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U7 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U8 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U9 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.1 J2.U10 [DCBO] Remote control : Custom (NTC, 4~20mA, Switch)
BE.2 J2.U1 [ADCP] Outside, Humidity 0~100%Hr (4~20mA)
BE.2 J2.U2 [RLKD] Circuit 1, Liquid Cooling mode (NTC)
BE.2 J2.U3 [RLKD] Circuit 1, Liquid Heating mode (NTC)
BE.2 J2.U4 [RLKD] Circuit 2, Liquid Cooling mode (NTC)
BE.2 J2.U5 [RLKD] Circuit 2, Liquid Heating mode (NTC)
BE.2 J2.U6 [VZH] Circuit 1, Discharge 1 (NTC 120)
BE.2 J2.U7
[Water Condenser, Unit 2 Circuits] Inlet (NTC)
[NSR] Blower Inverter in 0~10V Status (Switch)
BE.2 J2.U8
[Water Condenser, Unit 2 Circuits] Outlet (NTC)
[NSR] Blower Inverter (output 0~10V)
BE.2 J2.U9
[Unit circuit] [HWCS][HWCH] Hot/Cold Water Coil, Inlet (NTC)
[ADCP] Humidifi er, Status (Switch)
[NSR] Exhaust Fan Inverter in 0~10V Status (Switch)
BE.2 J2.U10
[ENRE] Hot/Cold Water Recovery, Inlet (NTC)
[DCBO] Humidifi er (output 0~10V)
[NSR] Exhaust Fan Inverter (output 0~10V)
BE.3 J2.U1 [TRMO] Circuit 3, Compressors, Status (Switch)
BE.3 J2.U2 [TRMO] Circuit 3, Condensing -1~45b (4~20mA)
BE.3 J2.U3 [TRMO] Circuit 3, Evaporating -1~20b (0~5V)
BE.3 J2.U4 [TRMO] Circuit 3, Suction (NTC)
BE.3 J2.U5 [TRMO, RLKD] Circuit 3, Liquid Cooling mode (NTC)
BE.3 J2.U6 [TRMO, RLKD] Circuit 3, Liquid Heating mode (NTC)
BE.3 J2.U7 [HRMO] Wheel Recovery, Motor Status (Switch)
BE.3 J2.U8 [HRMO] Wheel Recovery, Pressure 0~500pa (0~5V)
BE.3 J2.U9 [HRMO] Recovery, By-Pass (output 0~10V)
BE.3 J2.U10 [HRMO] Outside (NTC)
