APPENDIX 9
eCLIMATIC Outputs
BM
J16.NO1
J16.NC1
[PEFA] Exhaust Fan
BM J17.Out2
[CGBS] [CGBH] Valve 1
[ELHS][ELHM][ELHH] Electrical Heaters, 1
[HWCS][HWCH] Pump
BM J18.Out3
[CGBS] [CGBH] Valve 2
[ELHS][ELHM][ELHH] Electrical Heaters, 2
BM J19.Out4
Circuit 1, Condenser Fan
[Water Condenser] Pump
BM J20.Out5 Circuit 1, Reversing Valve
BM J21.V-IN
BM J22.NO6 Circuit 1, Compressor 1
BM J23.NO7 Circuit 1, Compressor 2
BM J24.NO8 Blower
BM
J27.NO9
J27.NC9
Circuit 2, Compressor 1
BM
J27.NO10
J27.NC10
Circuit 2, Compressor 2
BM J28.NO11 Circuit 2, Condenser Fan
BM J28.NO12 Circuit 2, Reversing Valve
BM J28.NO13 [ENRE ] Pump
BM J6.Y1
Economizer (0~10V)
[Aqualean] Water Condenser Valve (0~10V)
BM J6.Y2
[CGBS] [CGBH] Gas Modulation (0~10V)
[ELHH] Electrical Heaters (Triac 0~5V)
[HWCS][HWCH] Hot/Cold Water Coil, Valve (0~10V)
BM J6.Y3
[EPHS][EPHH] Electric Heaters Fresh Air (Triac 0~5V)
[ENRE] Hot/Cold Water Recovery, Valve (0~10V)
[PHMO] Plate Recovery, By-Pass (0~10V)
BM J26.Y4 [LWLT] Water Condenser Valve (0~10V)
BM J26.Y5
INPUTS / OUTPUTS CLIMATIC BOARDS
