Lennox CLIMATIC series

• 81 •CLIMATIC RT_UNITARY-IOM-1508-E
APPENDIX 9
eCLIMATIC Outputs
APPENDIX 10
eCLIMATIC Serial port
BE.1 J10.N1 [DCBO] Remote control : Custom
BE.1 J10.N2 [DCBO] Remote control : Custom
BE.1 J11.N3 [DCBO] Remote control : Custom
BE.1 J11.N4 [DCBO] Remote control : Custom
BE.1 J11.N5 [DCBO] Remote control : Custom
BE.1 J12.N6 [DCBO] Remote control : Custom
BE.2 J10.N1 [NSR] Exhaust Fan 1
BE.2 J10.N2 [NSR] Exhaust Fan 2
BE.2 J11.N3 [NSR] Exhaust Fan 3
BE.2 J11.N4
BE.2 J11.N5
BE.2 J12.N6 [ADCP] Humidifi er
BE.3 J10.N1 [TRMO] Circuit 3, Compressor 1
BE.3 J10.N2 [TRMO] Circuit 3, Compressor 2
BE.3 J11.N3 [TRMO] Circuit 3, Reversing Valve
BE.3 J11.N4
BE.3 J11.N5
BE.3 J12.N6 [HRMO] Wheel Recovery, Motor
BMS Card Option Unit BMS Bus
J15 Unit Display DS
J14 Unit
J29 Unit
J9 Unit
INPUTS / OUTPUTS CLIMATIC BOARDS
