Menu Description 4thdigit 3rddigit 2nddigit 1stdigit R/W/Z Min Std Max
2191
valueofthesignal,be‐1b1 Be.1‐B1 R ‐505
2192
valueofthesignal,be‐1b2 Be.1‐B2 R ‐505
2193
valueofthesignal,be‐1b3 Be.1‐B3 R ‐505
2194
valueofthesignal,be‐1b4 Be.1‐B4 R ‐505
2211
valueoftheoutsidetemperature Outside R ‐99,9 0 99,9
2212
OriginoftheValue(BM,BE,
BUS,Mast/SlavorBMS) From R 23 23 62
2213
valueoftheroomtemperature Room R ‐99,9 0 99,9
2214
OriginoftheValue(BM,BE,BUS,Mast/SlavorBMS) From R 23 23 62
2215
valueofthesupplytemperature Supply R ‐99,9 0 99,9
2216
valueofthereturntemperature Return R ‐99,9 0 99,9
2221
valueoftheroomtemperature Temp. R ‐99,9 0 99,9
2222
customer(dc/dm)setpoint SpCust. R/W 8 20,5 35
2223
setvalueof
coolingmode SetCool. R 8 19 35
2224
setvalueofheatingmode SetHeat. R 8 22 35
2225
statesofcoolingmode State.C R 23 23 62
2226
statesofheatingmode State.H R 23 23 62
2227
powerfactorofcoolingmode Pf.Cool. R 0 0 100
2228
powerfactorofheatingmode Pf.Heat. R 0 0 100
2231
valueofthesupplytemperature Temp. R ‐99,9 0 99,9
2232
Blowingairtemperaturesetpoint Setting R 1 20,5 70
2233
activationofthesmoothingfunctionoftemperature Smooth R/Z 0 0 1
2234
count
valueofcoolingoperatingtime Time.Cool R 0 0 9999
2235
countvalueofheatingoperatingtime Time.Heat R 0 0 9999
2241
Dynamicsetpoint(coolingsetpointoffsetaccordingtooutsidetemperature) Sp.Dyna. R/W/Z 0 20 20
2242
setpointofcoolingmode Sp.Cool. R/W/Z 8 19 35
2243
setpointofheatingmode Sp.Heat. R/W/Z 8 22 35
2244
outdoortemperaturelowthresholdforroomtemperaturesetpointslope Out.Low R/W ‐20 0 50
2245
roomtempsetpointoffsetaccordingto
lowoutdoorairtemp Coef.Low R/W ‐50 0 50
2246
outdoortemperaturehighthresholdforslopeontheroomtemperaturesetpoint Out.High R/W ‐20 30 50
2247
roomtempsetpointoffsetaccordingtohighoutdoorairtemp Coef.High R/W ‐50 0 50
2248
roomtemperaturethresholdforunloadingcoolingmode LimitC. R/W 0 0 40
2249
roomtemperaturethresholdforunloadingheatingmode LimitH. R/W 0 40 40
2251
lowlimitthresholdin
coolingmode Lim.Cool R/W 4 12 38
2252
highlimitthresholdinheatingmode Lim.Heat R/W 4 38 38
2253
offsetforhighlimitthresholdincoolingmode Adj.Cool R/W ‐505
2254
offsetforlowlimitthresholdinheatingmode Adj.Heat R/W ‐505
2255
outdoortemperaturelowthresholdforslopeonthesupplytemperaturesetpoint Out.Low R/W ‐20 0 50
2256
coefficientofthelowoutsidetemperaturefortheslopeof
thesupplytemperaturesetpoint Coef.Low R/W ‐50 0 50
2257
outdoortemperaturehighthresholdforslopeonthesupplytemperaturesetpoint Out.High R/W ‐20 30 50
2258
coefficientofthehighoutsidetemperaturefortheslopeofthesupplytemperaturesetpoint Coef.High R/W ‐50 0 50
2261
valueoftheoutsidehumidity Outside R 0 0 100
2262
calculatedvalueoftheoutsideabsolutehumidity Absol. R 0 0 99,9
2263
fromthevalue From R 23 23 62
2264
valueoftheroomhumidity Room R 0 0 100
2265
calculatedvalueoftheroomabsolutehumidity Absol. R 0 0 99,9
2266
fromthevalue From R 23 23 62
2267
powerfactorofdehumidificationfunction Pf.Deh. R 0 0 100
2268
powerfactorofhumidification Pf.Hum. R 0 0 100
2269
stateofenthalpycontrol Enthalpy R 0 0 1
