Menu Description 4thdigit 3rddigit 2nddigit 1stdigit R/W/Z Min Std Max
2431
stateofconfiguration Config. R 0 0 21
2432
statesofmanagement Status R 23 23 62
2433
stateoftheauxiliarycontact StateiD R 0 0 1
2434
stateoftherelay Relay R 0 0 1
2435
countvalueofoperatingtime RunTime R 0 0 9999
2441
stateofconfiguration Config. R 0 0 21
2442
valueoftheevaporatingpressureortemperature Evap. R ‐1 ‐120
2443
valueofthesuctiontemperature Suction R ‐99,9 0 99,9
2444
valueofthecondensingpressureor
temperature Cond. R ‐1 ‐145
2445
valueoftheliquidtemperature Liquid R ‐99,9 0 99,9
2446
lowpressure,stateofthesafety LowP. R 0 0 1
2447
stateofthereversingvalve R.Valve R 0 0 1
2451
stateofconfiguration Config. R 0 0 21
2452
statesofmanagement Status R 23 23 62
2453
stateoftheauxiliarycontact StateiD R 0 0 1
2454
stateoftherelay Relay R 0 0 1
2455
countvalueofoperatingtime RunTime R 0 0 9999
2461
stateofconfiguration Config. R 0 0 21
2462
statesofmanagement Status R 23 23 62
2463
stateoftheauxiliarycontact StateiD R 0 0 1
2464
stateoftherelay Relay R 0 0 1
2465
countvalueofoperatingtime RunTime R 0 0 9999
2471
setpointforactivationoperationofallcompressor,cooling/heatingmode Enabled R/W/Z 0 1 1
2472
enablecircuit1,separatecomp.1or/andcomp.2 Enable.1 R/W 0 3 3
2473
enablecircuit2,separatecomp.1or/andcomp.2 Enable.2 R/W 0 3 3
2481
setpointforactivationoperationin
coolingmode Enabled R/W/Z 0 1 1
2482
outsideairtemperaturethreshold,unload50%ofcompressors LowL50% R/W ‐10 20 50
2483
outsideairtemperaturethreshold,unload100%ofcompressors LowL. R/W ‐10 12 50
2491
setpointforactivationoperationinheatingmode Enabled R/W/Z 0 1 1
2492
outsideairtemperaturethreshold,unload50%ofcompressors LowL50% R/W ‐20 ‐20 50
2493
outsideairtemperaturethreshold,unload100%ofcompressors
LowL. R/W ‐20 ‐20 50
2511
stateofconfiguration Config. R 0 0 21
2512
valueofthecondensingtemperature Cond. R ‐99,9 0 99,9
2513
condensingtemperaturesetpoint Setting R 25 30 45
2514
statesofmanagement Status R 23 23 62
2515
stateoftheauxiliarycontact StateiD R 0 0 1
2516
stateoftherelay Relay R 0 0 1
2517
speedpercentagecalculatedfortheinverter Inverter R 0 0 100
2521
stateofconfiguration Config. R 0 0 21
2522
valueofthecondensingtemperature Cond. R ‐99,9 0 99,9
2523
condensing
temperaturesetpoint Setting R 25 30 45
2524
statesofmanagement Status R 23 23 62
2525
stateoftheauxiliarycontact StateiD R 0 0 1
2526
stateoftherelay Relay R 0 0 1
2527
speedpercentagecalculatedfortheinverter Inverter R 0 0 100
User
User
User
User
User
User
User
User
User
Compressor
Compressor
Condenser
Condenser
Compressor
Compressor
Compressor
Compressor
Compressor
Cooling
Heating
Circuit1
Circuit2
Circ.1Comp.2
Circuit2
Circ.2Comp.1
Circ.2Comp.2
Mode
CLIMATICRT_UNITARY‐IOM‐1508‐E .85.
