Lennox CLIMATIC series User Manual

Menu Description 4thdigit 3rddigit 2nddigit 1stdigit R/W/Z Min Std Max
2741
stateofconfiguration Config. R 0 0 21
2742
statesofmanagement Status R 23 23 62
2743
settingoffunctionality Mode R 0 0 3
2744
stateoftheauxiliarycontact StateiD R 0 0 1
2745
stateoftherelay Relay R 0 0 1
2751
stateofconfiguration Config. R 0 0 21
2752
statesofmanagement Status R 23 23 62
2753
openingpercentagecalculatedforthevalve Modul. R 0 0 100
2761
1stheaters,setpointforactivationoperationofcomponent Enable1 R/W/Z 0 1 1
2762
2ndheaters,setpointforactivationoperation
ofcomponent Enable2 R/W/Z 0 1 1
2771
1stheaters,setpointforpriorityinversionstarting Swap1 R/W/Z 0 0 3
2772
1stheaters,outsideairtemperaturethresholdforswapcontrol Swap1 R/W ‐20 10 50
2773
outsideairtemperaturethresholdforunload LowL.1 R/W ‐20 10 50
2774
2ndheaters,setpointforpriorityinversionstarting Swap2 R/W/Z 0 0 1
2811
stateofconfiguration Config. R 0 0 21
2812
statesofmanagement Status R 23 23 62
2813
minimumopeningsetting Minimum R 0 0 100
2814
openingpercentagecalculatedfortheactuator Opening R 0 0 100
2815
maximumopeningsetting Maximum R 0 100 100
2816
openingpercentagesendtotheactuator Output R 0 0 100
2821
statesofmanagement Status R 23 23 62
2822
valueofthesupplytemperature Supply R ‐99,9 0 99,9
2823
setpointofminimumfreshair Minimum R/W/Z 0 0 100
2824
setvalueofminimumfreshairin% SpCust. R 0 0 100
2825
setvalueofminimum
freshairin°c Setting R 1 20 70
2826
openingpercentagecalculated Request R 0 0 100
2827
Damperopeningvalueaftercalibration Calib. R 0 0 100
2828
valueoftheexternalsignalsetpoint 4‐20m
A
R 0 0 100
2831
statusoffreecooling Status R 23 23 62
2832
valueofthesupplytemperature Supply R ‐99,9 0 99,9
2833
temperaturethresholdforfreecoolingfunction Setting R 0 0 100
2834
powerfactorforfreecoolingfunction Power.F R 0 0 100
2841
statusoffreeheating Status R 23 23 62
2842
valueofthesupplytemperature Supply R ‐99,9 0 99,9
2843
temperaturethresholdforfreeheatingfunction Setting R 0 0 100
2844
powerfactorforfreeheatingfunction Power.F R 0 0 100
2851
stateofconfiguration Config. R 0 0 21
2852
statesofmanagement Status R 23 23 62
2853
value
ofairqualitysensor Value R 0 0 2000
2854
fromthevalue From R 24 29 29
2855
settingoffunctionality Mode R 0 0 1
2856
minimumthresholdforcontrol Minimum R 0 1000 2000
2857
maximumthresholdforcontrol Maximum R 0 1500 2000
2858
openingpercentagecalculated Request R 0 0 100
User
User
User
User
User
User
User
User
User
Heater
Economizer
Economizer
Economizer
Economizer
Economizer
Heater
Heater
Heater
Minimum
Free‐Cooling
Free‐Heating
AirQuality
Pump
HotWaterReco.
Mode
Control
Damper
CLIMATICRT_UNITARY‐IOM‐1508‐E .87.
