Menu Description 4thdigit 3rddigit 2nddigit 1stdigit R/W/Z Min Std Max
2861
stateofconfiguration Config. R 0 0 21
2862
statesofmanagement Status R 23 23 62
2863
1stlevel,stateoftherelay Relay1R 001
2864
2ndlevel,stateoftherelay Relay2R 001
2865
3rdlevel,stateoftherelay Relay3R 001
2866
speedpercentagecalculatedfortheinverter Inverter R 0 0 100
2871
stateofconfiguration Config. R 0 0 21
2872
statesofmanagement Status R 23 23 62
2873
valueoftheoutsidetemperature Outside R ‐99,9 0 99,9
2874
value
ofthereturntemperature Return R ‐99,9 0 99,9
2875
valueoftheoutlettemperature Outlet R ‐99,9 0 99,9
2876
valueofthedifferentialpressuresensor Delta.P R 0 0 1000
2877
openingpercentagecalculatedfortheby‐passdamper By‐pass R 0 0 100
2878
motorforwheelmodule,stateoftheauxiliarycontact WheelS. R 0 0 1
2879
motorforwheelmodule,stateoftherelay WheelR. R 0 0 1
2881
stateof
configuration Config. R 0 0 21
2882
statesofmanagement Status R 23 23 62
2883
calculatedvalueofthemixingtemperature Mixing R ‐99,9 0 99,9
2884
valueofthesupplytemperature Supply R ‐99,9 0 99,9
2885
setpoint Setting R 20 30 50
2886
stateoftheauxiliarycontact StateiD R 0 0 1
2887
stateoftherelay Relay R 0 0 1
2888
powerpercentagecalculatedforthetriac Pwm R 0 0 100
2889
powerpercentagesendtothetriac Output R 0 0 100
2911
stateofconfiguration Config. R 0 0 21
2912
statesof
management Status R 23 23 62
2913
openingpercentagecalculatedforthevalve Opening R 0 0 100
2921
stateofconfiguration Config. R 0 0 21
2922
statesofmanagement Status R 23 23 62
2923
stateoftheexternalsafetycontact StateiD R 0 0 1
2924
stateoftherelay Relay R 0 0 1
2925
powerpercentagecalculatedfortheproportionalsignal Opening R 0 0 100
2931
onlinestatus OnLine R 0 0 1
2932
valueoftherealpower RealPw R 0 0 3276,7
2933
valueofthereactivepower Reac.Pw R 0 0 3276,7
2934
value
ofthepowerfactor P‐Factor R ‐32768 0 32767
2935
valueofthecurrent,phasea Cur.P.1 R 0 0 999,9
2936
valueofthecurrent,phaseb Cur.P.2 R 0 0 999,9
2937
valueofthecurrent,phasec Cur.P.3 R 0 0 999,9
3111
unitrangeconfiguration Range R/W 0 0 20
3112
unitsizeconfiguration Size R/W 0 0 168
3113
optionsetpoint,quickstartafterpoweron QuickOn R/W 0 0 1
3114
optionsetpoint,specialfire/smoke
safety Public R/W 0 0 1
3121
settingoffunctionalityforrelaybmn7 Bm‐N7 R/W 30 30 57
3122
settingoffunctionalityforrelaybmn12 Bm‐N12 R/W 30 30 57
3123
settingoffunctionalityforrelaybe‐1n1 Be.1‐N1 R/W 30 30 57
3124
settingoffunctionalityforrelaybe‐1n2 Be.1‐N2 R/W 30 30 57
3125
settingoffunctionalityforrelaybe‐1n3 Be.1‐N3 R/W 30 30 57
3126
settingoffunctionality
forrelaybe‐1n4 Be.1‐N4 R/W 30 30 57
User
Expert
Expert
User
User
User
User
User
Unit
Unit
Economizer
Economizer
Economizer
Other
Other
Other
Heater
ChilledWater
Humififier
PowerMeter
Configuration
Cust.Relay
Exhaust
Recovery
CLIMATICRT_UNITARY‐IOM‐1508‐E .88.
