Menu Description 4thdigit 3rddigit 2nddigit 1stdigit R/W/Z Min Std Max
3131
settingoffunctionalityfordigitalinputbmid4 Bm‐iD4 R/W 30 30 66
3132
settingoffunctionalityfordigitalinputbmid7 Bm‐iD7 R/W 30 30 66
3133
settingoffunctionalityfordigitalinputbe‐1id1 Be.1‐iD1 R/W 30 30 66
3134
settingoffunctionalityfordigitalinputbe‐1id2 Be.1‐iD2 R/W 30 30 66
3135
settingoffunctionalityfordigitalinputbe‐1id3 Be.1‐iD3 R/W 30 30 66
3136
settingoffunctionalityfordigitalinputbe‐1id4 Be.1‐iD4 R/W 30 30 66
3141
settingoffunctionalityforanaloginputbe‐1b1 Be.1‐B1 R/W 30 30 39
3142
settingoffunctionalityforanaloginputbe‐1b2 Be.1‐B2 R/W 30 30 39
3143
settingoffunctionalityforanaloginputbe‐1b3 Be.1‐B3 R/W 30 30 39
3144
settingoffunctionalityforanaloginputbe‐1
b4 Be.1‐B4 R/W 30 30 39
3145
thresholdtemperaturefor4maexternalsensor T.4mA R/W ‐99,9 ‐40 99,9
3146
thresholdtemperaturefor20maexternalsensor T.20mA R/W ‐99,9 80 99,9
3151
DC60/DM60Configuration Remote R/W 0 0 1
3152
selectingthedisplaymodeforsetpoint(kor°c) SpCust. R/W 0 0 1
3153
lowerthresholdtemperatureforsetpointcustomer LowSp R/W 8 17 35
3154
upperthresholdtemperatureforsetpointcustomer
HighSp R/W 8 27 35
3155
activationoftheauthorizationtouseolddisplayorstandardcarel DSLennox R/W 0 0 1
3171
addressoftheunit(busid) Address R 1 1 24
3172
settingthesub‐bus Bus R/W 1 1 24
3173
settingthemasterofthebus Master R/W 0 0 24
3174
numberofcompressorsfortokenfunctionornumberofunits Number R/W 0 0 96
3175
settingoffunctionality Function R/W 0 0 4
3176
activationofthefunctionslaves
workslikemaster Together R/W 0 0 1
3177
choiceofoutsidetemperaturemanagement Outside R/W 0 0 2
3178
choiceofroomtemperaturemanagement Room R/W 0 0 2
3179
choiceofairqualitymanagement AirQ. R/W 0 0 2
3181
addressoftheunit(busid) Address R/W 1 1 207
3182
settingoftheprotocoltype Type R/W 0 2 6
3183
configurationofcommunicationbusspeed Baud R/W 0 3 4
3184
watchdogtimer Watchdog R/W 0 0 32767
3191
managementofsetpoints Restore R/W 0 0 5
3192
reservedfortechnicianslennox Tests R/W 7 7 48
3211
choiceofthecontrol(roomtemperatureorsupply) Mode R/W 0 0 1
3212
advancedcontrolpackconfiguration Humidity R/W 0 0 1
3213
choiceoftheroomsensortemperature RoomT. R/W 1 2 511
3214
choiceoftheoutsidesensortemperature Out.T. R/W 1 1 63
3215
choiceoftheroomsensorhumidity RoomHr. R/W 1 1 511
3216
choiceoftheoutsidesensorhumidity Out.Hr. R/W 1 1 63
3217
choiceofthesupplyairtemperaturesensor Supply R/W 1 1 3
Expert
Expert
Expert
Expert
Expert
Expert
Expert
Unit
Unit
Unit
Unit
Unit
Unit
Control Configuration
Cust.Switch
Cust.Signal
Dc‐Dm
Master/Slaves
Bms
Lennox
CLIMATICRT_UNITARY‐IOM‐1508‐E .89.
