Lennox eCOMFORT R32 GAC 035S

• 47 •
SPXX KGRL
DPXX WFIF
AVUB PHRF
GAC/H 095S-110S-115S
GAC-H_095S-110S-115S_H_R32_Z
GAC-H_095S-110S-115S_S_R32_Z
Installation manual / eCOMFORT R32-MIL166E-0222 - 09/2022
STANDARD VERSION OR WITH HIGH PRESSURE EC FANS (HIPF)
UNIT WITH STANDARD AC FANS (SFAC)
All dimensions in mm
All dimensions in mm
Hydraulic module with single pump Flange connection
Hydraulic module with twin pum Water lter (supplied loose)
Rubber anti-vibration mounts Domestic hot water supply : desuperheater
Victaulic or welded
connection
Flange connection Flange connection
Victaulic or welded
connection
Flange connection Flange connection
Controller connection
Ø 29
Controller connection
Ø 29
1.- GENERAL CHARACTERISTICS
1.9.- DIMENSIONS
