EL16XC1 - 1.5 to 5 Ton Air Conditioner / Page 10
TXV/ORIFICE USAGE
Use this table for C33, CH23, CH33, CH35 and CR33 Field
Installed TXV/Orice Match-Ups.
Model No. Refrigerant Metering
Orice (RFC)
Thermal
Expansion
Valve (TXV)
Order No. Orice Size
EL16XC1-018 97M74 0.053 12J18
EL16XC1-024 97M75 0.057 12J18
EL16XC1-030 10W99 0.065 12J18
EL16XC1-036 11W02 0.073 12J19
EL16XC1-041 97M77 0.074 12J20
EL16XC1-042 97M78 0.076 12J20
EL16XC1-047 10W86 0.080 12J20
EL16XC1-048 11W07 0.083 12J20
EL16XC1-060 11W11 0.093 12J20
MOST POPULAR MATCHES
Outdoor Unit
Model No.
Indoor Unit
Model No
EL16XC1-018 CX34-25
EL16XC1-024 CX34-25
EL16XC1-030 CX34-31
EL16XC1-036 CX34-38
EL16XC1-041 CX34-49
EL16XC1-042 CX34-49
EL16XC1-047 CX34-62C
EL16XC1-048 CX34-62C
EL16XC1-060 CX34-62C
AHRI STANDARD 210/240
supplementary heat. Power input is the total power input
to the compressor(s) and fan(s), plus any controls and
other items required as part of the system for normal
operation.
furnished as part of the model, i.e., split system with
adding the same amount to the heating capacity. Total
365 W per 1,000 cfm of indoor air circulated.
*TXV SUBSTITUTIONS
Use this table to determine if the factory installed TXV in
the indoor unit needs to be replaced.
Model
Indoor Coil or Air
Handler
Factory
TXV
Replacement
TXV
030 CX34-42
21J20
21J18
030 CX34-43
21J20
21J18
030 CX34/CX35-48
21J20
21J18
