EL16XC1 - 1.5 to 5 Ton Air Conditioner / Page 6
SPECIFICATIONS
General
Data
Model No. All Regions EL16XC1-018 EL16XC1-024 EL16XC1-030 EL16XC1-036
Nominal Tonnage 1.5 2 2.5 3
Connections
(sweat)
Liquid line (o.d.) - in. 3/8 3/8 3/8 3/8
Suction line (o.d.) - in. 3/4 3/4 3/4 7/8
Refrigerant
1
R-410A charge furnished
Outdoor
Coil
Net face area - sq. ft. Outer coil 13.22 16.33 21.00 18.66
Inner coil - - - - - - - - - 17.96
5/16 5/16 5/16 5/16
No. of rows 1 1 1 2
Fins per inch 26 26 26 22
Outdoor
Fan
Diameter - in. 18 22 22 22
3 3 3 3
Motor hp 1/10 1/6 1/6 1/6
Cfm 2290 3160 3160 3160
Rpm 1075 825 825 825
Watts 160 215 215 190
Shipping Data - lbs. 1 pkg. 155 171 187 223
ELECTRICAL DATA
Line voltage data - 60hz 208/230V-1ph 208/230V-1ph 208/230V-1ph 208/230V-1ph
2
Maximum overcurrent protection (amps) 20 25 25 30
3
Minimum circuit ampacity 11.9 14.6 17 18.6
Compressor Rated load amps 9.0 10.9 12.8 14.1
Locked rotor amps 48 59.3 67.8 79
Power factor 0.97 0.97 0.97 0.95
Outdoor Fan Motor Full load amps 0.7 1 1 1
Locked rotor amps 1.3 1.9 1.9 1.9
OPTIONAL ACCESSORIES - ORDER SEPARATELY
Compressor Crankcase Heater 93M04 • • • •
Compressor Hard Start Kit 10J42 • • • •
Compressor Low Ambient Cut-Off Switch 45F08 • • • •
Compressor Timed-Off Control 47J35 • • • •
Freezestat 93G35 • • • •
50A93 • • • •
Indoor Blower Off Delay Relay 58M81 • • • •
Loss of Charge Switch Kit 84M23 • • • •
4
Low Ambient Kit (Fan Cycling) 34M72 • • • •
Refrigerant
Line Sets
L15-41-20
L15-41-30
L15-41-40
L15-41-50
• • •
L15-65-40 L15-65-40
L15-65-50
•
1
additional refrigerant charge required.
2
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
4
