SPECIFICATIONS
General
Data
Model No. All Regions EL16XC1-041 EL16XC1-042 EL16XC1-047 EL16XC1-048 EL16XC1-060
Nominal Tonnage 3.5 3.5 4 4 5
Connections
(sweat)
Liquid line (o.d.) - in. 3/8 3/8 3/8 3/8 3/8
Suction line (o.d.) - in. 7/8 7/8 7/8 7/8 1-1/8
Refrigerant
1
R-410A charge furnished
Outdoor
Coil
Net face area - sq. ft. Outer coil 21.00 21.00 22.17 21.00 22.17
Inner coil 20.25 20.25 21.33 20.25 21.33
5/16 5/16 5/16 5/16 5/16
No. of rows 2 2 2 2 2
Fins per inch 22 22 22 22 22
Outdoor
Fan
Diameter - in. 22 22 26 22 26
3 3 4 4 4
Motor hp 1/6 1/6 1/3 ¼ 1/3
Cfm 3050 3050 4400 3600 4400
Rpm 825 825 825 825 825
Watts 190 190 310 310 310
Shipping Data - lbs. 1 pkg. 227 234 272 255 277
ELECTRICAL DATA
Line voltage data - 60hz 208/230V-1ph 208/230V-1ph 208/230V-1ph 208/230V-1ph 208/230V-1ph
2
Maximum overcurrent protection (amps) 30 40 35 40 50
3
Minimum circuit ampacity 19.3 23.4 21.9 24.2 29.6
Compressor Rated load amps 14.7 17.9 16.1 18.0 22.2
Locked rotor amps 75 112 105.5 117 127.9
Power factor 0.96 0.96 0.98 0.96 0.98
Outdoor Fan Motor Full load amps 1 1 1.8 1.7 1.8
Locked rotor amps 1.9 1.9 2.9 3.2 2.9
OPTIONAL ACCESSORIES - ORDER SEPARATELY
Compressor Crankcase Heater 93M04 • •
Factory • • •
Compressor Hard Start Kit 10J42 • • • • •
Compressor Low Ambient Cut-Off Switch 45F08 • • • • •
Compressor Timed-Off Control 47J35 • • • • •
Freezestat 93G35 • • • • •
50A93 • • • • •
Indoor Blower Off Delay Relay 58M81 • • • • •
Loss of Charge Switch Kit 84M23 • • • • •
4
Low Ambient Kit (Fan Cycling) 34M72 • • • • •
Refrigerant
Line Sets
L15-65-40 L15-65-40
L15-65-50
• • • •
•
1
additional refrigerant charge required.
2
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
4
To Next Page
