EL180UHE Gas Furnace
The EL180UHE unit is shipped ready for installation in the
upow or horizontal right position (for horizontal left posi-
tion the combustion air pressure switch must be moved)
fueled by natural gas. A conversion kit (ordered separate-
ly) is required for use in LP/Propane gas applications. The
furnace is shipped with the bottom panel in place. The bot-
tom panel must be removed if the unit is to be installed in
a horizontal application. The panel may also be removed
in upow applications.
Shipping and Packing List
Package 1 of 1 contains
1 - Assembled EL180UHE unit
1 - Bag assembly containing the following:
2 - Screws
1 - Snap bushing
1 - Snap plug
1 - Wire tie
1 -Vent warning label
1 - Owner’s manual and warranty card
The following items may be ordered separately:
1 - Thermostat
1 - Suspension kit (for horizontal installations)
1 - LP/Propane changeover kit
1 - Return air base
1 - High altitude kit
1 - Side lter kit
Check equipment for shipping damage. If you nd any
damage, immediately contact the last carrier.
Shipping and Packing List
DANGER
Danger of explosion.
There are circumstances in which odorant used with
LP/propane gas can lose its scent. In case of a leak,
LP/propane gas will settle close to the oor and may be
difcult to smell. An LP/propane leak detector should
be installed in all LP applications.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer or
equivalent, service agency, or the gas supplier.
Certications
EL180UHE units are CSA International certied to
ANSI Z21.47.
In the USA, installation of gas furnaces must con-
form with local building codes. In the absence of lo-
cal codes, units must be installed according to the
current National Fuel Gas Code (ANSI-Z223.1). The
National Fuel Gas Code is available from the follow-
ing address:
American National Standards Institute, Inc.
11 West 42nd Street
New York, NY 10036
Clearances
Adequate clearance must be made around the air
openings into the vestibule area. In order to ensure
proper unit operation, combustion and ventilation air
supply must be provided according to the current
National Fuel Gas Code. Vent installations must be
consistent with the National Fuel Gas Code venting
tables (in this instruction) and applicable provisions
of local building codes.
This furnace is CSA International certied for instal-
lation clearances to combustible material as listed on
the unit nameplate and in the tables in gures 7 and
11. Accessibility and service clearances must take
precedence over re protection clearances.
NOTE - For installation on combustible oors, the
furnace shall not be installed directly on carpeting,
tile, or other combustible material other than wood
ooring.
Installed Locations
For installation in a residential garage, the furnace
must be installed so that the burner(s) and the igni-
tion source are located no less than 18 inches (457
mm) above the oor. The furnace must be located
or protected to avoid physical damage by vehicles.
When a furnace is installed in a public garage, han-
gar, or other building that has a hazardous atmo-
sphere, the furnace must be installed according to
recommended good practice requirements and cur-
rent National Fuel Gas Code.
Temperature Rise
NOTE - Furnace must be adjusted to obtain a tem-
perature rise within the range specied on the unit
nameplate. Failure to do so may cause erratic lim-
it operation and may result in premature heat ex-
changer failure.
This EL180UHE furnace must be installed so that its
electrical components are protected from water.
