Lennox ELITE 12GCS Series

Page 5
SPECIFICATIONS 12CHP
Model No. 12CHP024 12CHP030 12CHP036 12CHP042 12CHP048 12CHP060
Cooling Capacity  Btuh (kW) 23,800 (7.0) 28,000 (8.2) 35,000 (10.2) 42,000 (12.3) 48,000 (14.0) 57,000 (16.7)
ARI
Cooling
Total unit watts 2160 2550 3210 3930 4510 5230
C
oo
li
ng
Ratin
g
s
SEER (Btuh/Watts) 12.00 12.00 12.00 12.00 12.00 12.00
Ratings
EER (Btuh/Watts) 11.00 11.00 10.90 10.70 10.65 10.90
ARI Certified
Total Capacity  Btuh (kW) 24,000 (7.0) 29,400 (8.6) 35,000 (10.2) 42,000 (12.3) 48,000 (14.0) 57,000 (16.7)
ARI
C
er
tifi
e
d
High
Total unit watts 2230 2610 3150 3850 4690 5220
High
Temperature
Heating Ratings
C.O.P (Coefficient of Performance) 3.16 3.30 3.26 3.20 3.00 3.20
Heating Ratings
HSPF  Region IV 7.00 7.00 7.20 7.20 7.00 7.00
ARI Certified
Lo
Total Capacity  Btuh (kW) 14,800 (4.3) 17,500 (5.1) 21,800 (6.4) 25,600 (7.5) 31,000 (9.1) 37,300 (10.9)
Low
Te m
p
erature
Total unit watts 2100 2420 2960 3570 4330 5200
Temperature
Heating Ratings
C.O.P (Coefficient of Performance) 2.06 2.12 2.16 2.10 2.10 2.10
Sound Rating Number (db) 76 80
Refrigerant Charge (HCFC−22)
7 lbs. 5 oz.
(3.32 kg)
7 lbs. 4 oz.
(3.29 kg)
11 lbs. 0 oz.
(4.99 kg)
10 lbs. 12 oz.
(4.59 kg)
12 lbs. 3 oz.
(5.53 kg)
10 lbs. 13 oz.
(4.90 kg)
Indoor Coil
Blower wheel size D x W in. (mm) 10 x 7 (254 x 178) 10 x 8 (254 x 203) 10 x 10 (254 x 254)
Indoor
Coil
Blower
Motor horsepower (W) 1/2 (373) 3/4 (559)
Indoor
Net face area − sq. ft. (m
2
) 3.6 (0.33) 4.2 (0.39) 6.1 (0.57)
Indoor
Coil
Tube dia. − in. (mm) & No. of rows 5/16 (7.9) − 3 3/8 (9.5) − 3
Coil
Fins per inch (m) 14 (552) 15 (591)
Outdoor
Net face area − sq. ft. (m
2
) 12.3 (1.14) 14 (1.3) 14.3 (1.33) 17.5 (1.63)
Outdoor
Coil
Tube dia. − in. (mm) & No. of rows 5/16 (7.9) − 2 3/8 (9.5) − 2
Coil
Fins per inch (m) 18 (709) 14 (552) 12 (473) 16 (630)
Diameter − in. (mm) & No. of blades 18 (457) − 4 20 (508) − 4
Outdoor
Air Volume − cfm (L/s) 2300 (1085) 3000 (1415)
Outdoor
Coil Fan
Motor horsepower (W) 1/4 (187)
Motor watts 250 325
Condensate drain size fpt − in. (mm) (1) 3/4 (19)
No. & size of filters − in. (mm)
(1) 24 x 25 x 1
(610 x 635 x 25)
(1) 28 x 25 x 1
(711 x 635 x 25)
(1) 30 x 30 x 1 (762 x 762 x 25)
Net weight of basic unit − lbs. (kg) 275 (125) 310 (141) 420 (191) 425 (193) 435 (197) 455 (206)
Shipping weight of basic unit − lbs. (kg) (1 Package) 290 (132) 325 (147) 435 (197) 440 (200) 450 (204) 470 (213)
Electrical characteristics 208−230v, 1ph, 60hz
OPTIONAL ACCESSORIES − MUST BE ORDERED EXTRA
Supplemental Electric Heat − kW range 05,07,10 05,07,10,15 10,15,20
Timed-Off Control 42K90
Outdoor
Thermostat Kit LB−29740BA (56A87)
Outdoor
Thermostat Kit
Mounting Box M−1595 (31461)
High Pressure Switch 42K89
Rated in accordance with ARI Standard 210/240; 95_F (35_C) outdoor air temperature, 80_F (27_C) db/67_F (19_C) wb entering evaporator air.
Filters are not furnished and must be ordered extra.
ELECTRICAL 12CHP
ModelNo. 12CHP024 12CHP030 12CHP036 12CHP042 12CHP048 12CHP060
Linevoltagedata − 60hz 1 phase 208/230v
Recommendedmaximumfusesize or
circuit breaker size(amps)
25 30 30 35 40 50
MinimumCircuitAmpacity 18.2 19.8 23.6 27.6 29.4 36.7
Compressor
Ratedloadamps 10.9 12.2 14.7 17.9 19.2 25.0
C
ompressor
Lockedrotoramps 54 67 83 104 137 169
Outdoor
Coil
Fullloadamps 1.8
C
o
il
FanMotor
Lockedrotoramps 3.8
Indoor
Coil
Fullloadamps 2.7 3.4 3.6
C
o
il
Blower Motor
Lockedrotoramps 5.5 8.3 11 7.3
Unitpowerfactor .96 .97 .95 .97 .99 1.00
Where current does not exceed 100 amps, HACR type circuit breaker may be used in place of fuse (U.S. only).
RefertoNational or CanadianElectricalCodemanualtodeterminewire,fuseanddisconnectsizerequirement
NOTE−Extremesofoperatingrangeareplusandminus10%ofline voltage.
