Page 7
FIGURE 1
BLOWER MOTOR
HEAT EXCHANGER
ASSEMBLY
COMBUSTION AIR
INDUCER
GAS VALVE
GAS
MANIFOLD
COMBUSTION AIR
PROVE SWITCH
SCROLL
COMPRESSOR
CONDENSER COIL
CONDENSER FAN
12GCS PARTS ARRANGEMENT
FIGURE 2
12CHP PARTS ARRANGEMENT
CAPACITOR
OUTDOOR COIL
OUTDOOR FAN
DEFROST CONTROL
REVERSING VALVE
SCROLL COMPRESSOR
