Page 8
FIGURE 3
12GCS CONTROL BOX
IGNITION/BLOWER
CONTROL
(A3)
TRANSFORMER
(T1)
CONTACTOR
(K1)
DUAL/FAN CAPACITOR
(C12)
FIGURE 4
12CHP CONTROL BOX
DUAL / FAN CAPACITOR
(C12)
DEFROST CONTROL
(CMCI)
TRANSFORMER
(T1)
CONTACTOR
(K1)
BLOWER CONTROL
(A15)
T1T2T3
