Page 18
OPTIONAL ELECTRIC HEAT DATA - EL240XA
Electric Heat
Size
No.
of
Steps
Volts
Input
kW
Input
1
Btuh
Output
2
Total Unit + Electric Heat
Minimum Circuit
Ampacity
Total Unit + Electric Heat
Maximum Overcurrent
Protection
5 hp 7.5 hp 5 hp 7.5 hp
20 kW 1 208 14.8 50,600 73 82 80 90
220 16.5 56,500
1 230 18.1 61,800 81 90 90 90
240 19.7 67,300
440 16.8 57,500
1 460 18.4 62,900 40 44 40 45
480 20 68,300
550 16.7 57,300
1 575 18.4 62,600 32 36 35 40
600 20 68,300
30 kW 2 208 22.5 76,900 99 109 100 110
220 25.2 86,100
2 230 27.6 94,100 112121 125 125
240 30 102,500
440 25.2 86,100
1 460 27.6 94,100 55 59 60 60
480 30 102,500
550 25.2 86,100
1 575 27.6 94,200 44 48 45 50
600 30 102,500
40 kW 2 208 29.3 100,000 123132 125 150
220 32.8 112,000
2 230 35.8 122,300 139148 150 150
240 39 133,200
440 32.8 112,000
1 460 35.9 122,400 69 73 70 80
480 39 133,200
550 33.6 114,800
1 575 36.7 125,500 56 60 60 60
600 40 136,600
50 kW 2 208 36.1 123,200 121131 125 150
220 40.3 137,700
2 230 44.1 150,600 137146 150 150
240 48 163,900
440 42 143,400
2 460 45.9 156,700 81 91 90 100
480 50 170,800
550 42 143,500
2 575 45.9 156,800 69 79 70 80
600 50 170,800
1
Electric heater capacity only - does not include additional blower motor heat capacity.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements. Use wires suitable for at least 167°F.
