Lennox G21Q Series Unit Information

Page 99
MATCH UP JUMPER COMMENTS OR SEQUENCE WIRING CONNECTIONS
G21V/GSR21V OPERATION SEQUENCE AND JUMPERS SUMMARY WITH VSP1 (COOLING)
TABLE 22 (contd.)
Harmony and Two
Speed Compressor
No Jumpers
Harmony and Single
Speed Compressor
No Jumpers
Blower operates on
PWM signal generated
by Harmony. Harmony
overrides blower speed
taps. Blower speed varies
according to zone de
mand.
Blower operates on
PWM signal generated
by Harmony. Harmony
overrides blower speed
taps. Blower speed varies
according to zone de
mand.
(continued from previous page)
W1
W2
R
G
Y1
Y2
DS
C
HB
CCB1 with TwoSpeed
Compressor, no Har
mony
Blower speed is controlled by
the DC signal from CCB1.
Blower operates on low speed
heat/cool tap during dehumidi
fication. Otherwise, blower op
erates on high speed cool tap
during high speed compressor
operation and low speed heat/
cool tap during low speed
compressor operation
No Jumpers
A20 HUMIDITY CONTROL
S1
THERMOSTAT
TO
OUTDOOR
UNIT
W1
W2
R
G
Y1
Y2
DS
C
HB
W1
W2
R
G
Y1
Y2
DS
C
HB
TO
OUTDOOR
UNIT
TO
OUTDOOR
UNIT
TB1 TERMINAL STRIP
TB1 TERMINAL STRIP
TB1 TERMINAL STRIP
ZONE
CONTROLLER
A1
HARMONY
ZONE
CONTROLLER
A1
HARMONY
FOR HEATING JUMPERS
SEE TABLE 21
