NOTES − All air data is measured external to unit with 1 in. cleanable filter (not furnished − field provided) in place.
Air volume based on bottom air return air. Actual air volume may vary on side return air applications.
G60UH−48B−090 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
Medium−
High
Medium−
Low
Low
cfm Watt cfm Watt cfm Watt cfm Watt
0.00 1970 790 1810 735 1585 670 1340 565
0.05 1940 780 1785 715 1580 650 1335 555
0.10 1915
765 1760 695 1570 630 1325 540
0.15
1880 745 1730 660 1560 615 1325 530
0.20 1840 730 1700 620 1545 600 1320 520
0.25 1805
715 1670 625 1520 585 1310 510
0.30
1765 695 1640 625 1490 565 1295 500
0.40 1695 670 1570 595 1440 540 1260 480
0.50 1600
635 1490 560 1360 505 1195 450
0.60
1505 600 1400 530 1285 480 1140 425
0.70 1395 565 1265 485 1170 440 990 380
0.80 1250
520 1100 445 975 390 905 355
0.90
1005 460 870 385 900 365 810 325
G60UH−48C−110 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
Medium−
High
Medium−
Low
Low
cfm Watt cfm Watt cfm Watt cfm Watt
0.00 2015 895 1620 780 1340 640 1150 525
0.05 1990 870 1615 760 1340 640 1150 525
0.10 1965
850 1610 745 1340 640 1150 525
0.15
1930 825 1605 725 1335 630 1150 525
0.20 1895 805 1600 710 1335 615 1150 525
0.25 1860
785 1590 695 1330 605 1150 520
0.30
1820 765 1580 675 1330 590 1145 515
0.40 1740 725 1530 635 1320 560 1140 490
0.50 1665
695 1475 600 1285 525 1120 470
0.60
1575 650 1405 555 1230 490 1075 445
0.70 1475 610 1310 515 1165 470 1015 415
0.80 1350
560 1210 485 1080 430 930 380
0.90
1210 520 1070 430 870 365 740 325
G60UH−60C−100X PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Different Blower Speeds
Bottom Return Air, Side Return Air with Optional RAB
Return Air Base, Return Air from Both Sides or Return
Air from Bottom and One Side.
Single Side Return Air − Air volumes in bold require field
fabricated transition to accommodate 20 x 25 x 1 in. air
filter in order to maintain proper air velocity.
High Medium−High Medium−Low Low High Medium−High Medium−Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
.00 2555 1378 2300 1027 1985 863 1655 678 2385 1296 2185 981 1915 836 1650 686
.10 2490 1354 2265 1002 1980 839 1640 667 2330 1274 2150 961 1900 815 1635 677
.20 2420 1330 2225 980 1975 832 1635 660 2255 1234 2095 930 1885 794 1625 664
.30 2355 1300 2175 957 1945 810 1625 653 2190 1207 2035 902 1855 769 1620 651
.40 2275 1265 2115 934 1915 785 1620 639 2115 1179 1970 876 1820 751 1605 639
.50 2175 1229 2040 903 1860 762 1595 623 2055 1156 1905 853 1760 725 1575 622
.60 2085 1199 1965 873 1800 733 1565 608 1985 1141 1830 827 1705 704 1525 602
.70 1990 1140 1870 843 1730 714 1525 590 1910 1119 1745 797 1635 680 1475 582
.80 1890 1105 1770 807 1630 676 1455 567 1810 1088 1650 772 1560 659 1430 571
.90 1760 1067 1655 777 1535 649 1370 541 1715 1058 1570 751 1485 638 1355 549
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place.
G60UH−60D−135 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Different Blower Speeds
Bottom Return Air, Side Return Air with Optional RAB
Return Air Base, Return Air from Both Sides or Return
Air from Bottom and One Side.
Single Side Return Air − Air volumes in bold require field
fabricated transition to accommodate 20 x 25 x 1 in. air
filter in order to maintain proper air velocity.
High Medium−High Medium−Low Low High Medium−High Medium−Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
.00
2715 1407 2255 1070 1910 850 1660 674 2455 1336 2170 1019 1850 829 1555 673
.10 2640 1403 2250 1030 1900 834 1645 668 2380 1299 2140 974 1840 812 1550 664
.20 2540 1355 2245 1006 1890 821 1630 665 2305 1266 2105 947 1830 791 1545 656
.30 2480 1319 2200 975 1890 781 1625 656 2235 1234 2045 914 1820 774 1540 642
.40 2390 1282 2155 940 1885 775 1615 642 2160 1240 1985 886 1800 755 1540 628
.50 2320 1251 2085 904 1860 758 1605 631 2065 1170 1925 863 1745 726 1535 614
.60 2205 1210 2020 876 1815 731 1595 611 1990 1146 1870 844 1700 706 1505 599
.70 2080 1161 1935 839 1760 707 1545 588 1895 1111 1775 808 1655 689 1465 573
.80 2010 1122 1855 810 1690 679 1495 568 1805 1074 1680 779 1565 656 1425 562
.90 1880 1071 1755 781 1585 646 1430 545 1695 1042 1590 752 1480 630 1335 533
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place.
