Lennox G60UH Series User Manual

Page 33
G60UH Series
Blower Performance Data
NOTES − All air data is measured external to unit with 1 in. cleanable filter (not furnished − field provided) in place.
Air volume based on bottom air return air. Actual air volume may vary on side return air applications.
G60UH−24A−070 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium Low
cfm Watts cfm Watts cfm Watts
0.00 1075 445 905 375 730 290
0.05 1070 445 900 375 725 290
0.10 1065
440 895 370 720 285
0.15
1060 435 890 365 715 285
0.20 1055 430 885 360 710 280
0.25 1045
425 880 360 700 280
0.30
1030 415 875 355 690 270
0.40 1010 400 860 350 675 270
0.50 975
390 840 340 660 265
0.60
940 375 805 325 640 255
0.70 890 360 755 305 605 240
0.80 830
340 700 285 565 225
0.90
765 305 640 265 515 205
G60UH−36A−070 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
Medium−
High
Medium−
Low
Low
cfm Watt cfm Watt cfm Watt cfm Watt
0.00 1500 705 1290 565 985 455 830 375
0.05 1475 695 1275 555 980 445 820 365
0.10 1450
680 1255 545 970 440 810 360
0.15
1425 670 1240 535 965 430 805 355
0.20 1400 655 1225 525 955 425 795 350
0.25 1370
645 1205 510 945 415 790 345
0.30
1340 630 1180 500 930 405 780 335
0.40 1285 610 1140 475 900 390 745 325
0.50 1215
580 1080 450 865 375 705 310
0.60
1150 560 1015 430 810 355 655 290
0.70 1060 535 940 405 730 330 585 270
0.80 955
515 800 370 655 305 480 260
0.90
785 475 605 325 585 270 410 255
G60UH−36B−090 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
Medium−
High
Medium−
Low
Low
cfm Watt cfm Watt cfm Watt cfm Watt
0.00 1500 720 1255 595 1040 460 900 370
0.05 1485 705 1250 580 1040 450 895 365
0.10 1465
685 1240 570 1035 445 890 360
0.15
1450 675 1235 555 1035 440 885 355
0.20 1435 660 1225 545 1030 435 880 350
0.25 1420
645 1215 530 1025 425 875 345
0.30
1400 630 1200 520 1020 415 870 340
0.40 1345 595 1170 495 1000 400 855 330
0.50 1300
575 1135 475 965 380 830 300
0.60
1235 545 1080 445 930 360 780 290
0.70 1165 510 1020 415 870 340 740 280
0.80 1080
480 940 385 800 315 670 260
0.90
985 445 840 355 710 290 600 245
G60UH−36C−110 PERFORMANCE
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
Medium−
High
Medium−
Low
Low
cfm Watt cfm Watt cfm Watt cfm Watt
0.00 1555 715 1335 575 1085 460 925 365
0.05 1540 705 1330 555 1080 450 920 360
0.10 1525
690 1320 545 1075 440 915 355
0.15
1510 680 1310 535 1070 430 910 350
0.20 1490 670 1295 525 1065 420 900 340
0.25 1465
655 1280 510 1060 415 890 335
0.30
1440 645 1260 495 1050 405 880 330
0.40 1385 615 1230 485 1030 390 865 320
0.50 1320
590 1190 460 995 375 835 300
0.60
1260 570 1135 430 960 355 815 295
0.70 1190 545 1075 410 915 345 775 285
0.80 1090
515 970 385 860 325 760 280
0.90
975 485 880 360 790 305 705 275
