Page 2

SPECIFICATIONS

Gas

Heating

Performance

ModelNo. G60UH−24A−045 G60UH−24A−070 G60UH−36A−070

Low NOx Model No. G60UH−24A−045X − − − G60UH−36A−070X

Input− Btuh (kW) low fire 30,000 (8.8) 45,000 (13.2) 45,000 (13.2)

Output− Btuh (kW) low fire 24,000 (7.0) 36,000 (10.6) 36,000 (10.6)

Input− Btuh (kW) high fire 44,000 (12.9) 66,000 (19.3) 66,000 (19.3)

Output− Btuh (kW) high fire 36,000 (10.5) 54,000 (15.8) 54,000 (15.8)

AFUE 80.0% 80.0% 80.0%

California Seasonal Efficiency 73.1 74.2 73.9

Highstatic(AGA/CGA)− in.w.g. (Pa) .50 (124) .50 (124) .50 (124)

Temperature rise range − F (C) low fire 15 − 45 (8 − 25) 20 − 50 (11 − 28) 20 − 50 (11 − 28)

Temperature rise range − F (C) high fire 35 − 65 (19 − 36) 40 − 70 (22 − 39) 40 − 70 (22 − 39)

Connections

Flue connection − in. (mm) round 4 (102) 4 (102) 4 (102)

GaspipesizeIPS− in. (mm) 1/2 (12.7) 1/2 (12.7) 1/2 (12.7)

Indoor

Blower

Wheelnominaldiameter xwidth −in. (mm) 10 x 7 (254 x 178) 10 x 7 (254 x 178) 10 x 8 (254 x 203)

ower

Motoroutput − hp (W) 1/5 (149) 1/5 (149) 1/3 (249)

Tons(kW) ofadd-oncooling 2 (7.0) 2 (7.0) 2 − 3 (7.0 − 10.6)

Shippingweight − 1 package 121 lbs. (55 kg) 127 lbs. (58 kg) 132 lbs. (60 kg)

Matching Coils

Up−flow cased C33−18A−2F, C33−24A−2F, C33−30A−2F, C33−36A−2F, C33−38A−2F

Horizontal CH33−18A−2F, CH33−24/30A−2F, CH33−36A−2F

Electricalcharacteristics 120 volts − 60 hertz − 1 phase (less than 12 amps)

OPTIONAL ACCESSORIES − MUST BE ORDERED EXTRA

 Air Filter and Rack Kit

Number and size of filters

Horizontal (end) 87L95 − (1) 14 x 25 x 1 in. (356 x 635 x 25 mm)

er an

ze o

filt

ers

Side Return Single (44J22) or Ten Pack (66K63) − (1) 16 x 25 x 1 in. (406 x 635 x 25 mm)

EZ Filter Base

Catalog Number − Shipping Weight 73P55 − 6 lbs. (3 kg)

Dimensions − H x W x D 4 x 14−1/4 x 28−5/8 in. (102 x 362 x 727 mm)

Number and size of filter (field provided) 14 x 25 x 1 in. (356 x 635 x 25 mm)

Horizontal Support Frame Kit − Shipping Weight 56J18  18 lbs. (8 kg)

Vent Adaptor − 6 in. 152 (mm) connection size 18M79 − 2 lbs. (1 kg) 18M79 − 2 lbs. (1 kg) 18M79 − 2 lbs. (1 kg)

High Altitude See Page 10

Propane/Natural Gas Kit 0 to 7500 ft (0 − 2286m 59M87

Annual Fuel Utilization Efficiency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.

NOTE − Filters and provisions for mounting are not furnished and must be field provided.

 The same C33 uncased models match the furnaces shown but require an optional adaptor base or field fabricated transition. See C33 coil bulletin for additional information.

 Cleanable polyurethane frame type filter.
