Page 5
BLOWER DATA
G60UH−24A−045 PERFORMANCE
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 1090 515 460 905 425 390 725 340 300
0.05 12 1080 510 450 900 425 390 720 340 300
0.10 25 1065 505 445 895 420 385 710 335 295
0.15 37 1050 495 435 895 420 380 700 330 290
0.20 50 1030 485 425 890 420 375 690 325 290
0.25 62 1015 480 415 875 415 370 680 320 285
0.30 75 995 470 410 860 405 365 665 315 280
0.40 100 960 455 395 840 395 350 650 305 270
0.50 125 910 430 380 795 375 335 610 290 260
0.60 150 840 395 355 750 355 315 540 255 245
0.70 175 770 365 340 665 315 295 490 230 235
0.80 200 660 310 315 555 260 275 420 200 225
0.90 225 560 265 295 480 225 260 355 170 210
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
NOTE − Air volumes based on bottom return air. Actual air volume may vary on side return air applications.
G60UH−24A−070 PERFORMANCE
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 1075 505 445 905 425 375 730 345 290
0.05 12 1070 505 445 900 425 375 725 340 290
0.10 25 1065 505 440 895 420 370 720 340 285
0.15 37 1060 500 435 890 420 365 715 335 285
0.20 50 1055 500 430 885 420 360 710 335 280
0.25 62 1045 495 425 880 415 360 700 330 280
0.30 75 1030 485 415 875 415 355 690 325 270
0.40 100 1010 475 400 860 405 350 675 320 270
0.50 125 975 460 390 840 395 340 660 310 265
0.60 150 940 445 375 805 380 325 640 300 255
0.70 175 890 420 360 755 355 305 605 285 240
0.80 200 830 390 340 700 330 285 565 265 225
0.90 225 765 360 305 640 300 265 515 245 205
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
NOTE − Air volumes based on bottom return air. Actual air volume may vary on side return air applications.
G60UH−36A−070 PERFORMANCE
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 1500 710 705 1290 610 565 985 465 455 830 390 375
0.05 12 1475 695 695 1275 600 555 980 465 445 820 385 365
0.10 25 1450 685 680 1255 590 545 970 460 440 810 380 360
0.15 37 1425 675 670 1240 585 535 965 455 430 805 380 355
0.20 50 1400 660 655 1225 580 525 955 450 425 795 375 350
0.25 62 1370 645 645 1205 570 510 945 445 415 790 375 345
0.30 75 1340 630 630 1180 555 500 930 440 405 780 370 335
0.40 100 1285 605 610 1140 540 475 900 425 390 745 350 325
0.50 125 1215 575 580 1080 510 450 865 410 375 705 335 310
0.60 150 1150 545 560 1015 480 430 810 380 355 655 310 290
0.70 175 1060 500 535 940 445 405 730 345 330 585 275 270
0.80 200 955 450 515 800 375 370 655 310 305 480 225 260
0.90 225 785 370 475 605 285 325 585 275 270 410 195 255
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
NOTE − Air volumes based on bottom return air. Actual air volume may vary on side return air applications.
