Page 6

BLOWER DATA Cont.

G60UH−36B−090 PERFORMANCE

External Static

Air Volume / Watts at Various Blower Speeds

External

Static

Pressure

High Medium−High Medium−Low Low

in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts

0.00 0 1500 710 720 1255 590 595 1040 490 460 900 425 370

0.05 12 1485 700 705 1250 590 580 1040 490 450 895 420 365

0.10 25 1465 690 685 1240 585 570 1035 490 445 890 420 360

0.15 37 1450 685 675 1235 585 555 1035 490 440 885 420 355

0.20 50 1435 675 660 1225 580 545 1030 485 435 880 415 350

0.25 62 1420 670 645 1215 575 530 1025 485 425 875 415 345

0.30 75 1400 660 630 1200 565 520 1020 480 415 870 410 340

0.40 100 1345 635 595 1170 550 495 1000 470 400 855 405 330

0.50 125 1300 615 575 1135 535 475 965 455 380 830 390 300

0.60 150 1235 585 545 1080 510 445 930 440 360 780 370 290

0.70 175 1165 550 510 1020 480 415 870 410 340 740 350 280

0.80 200 1080 510 480 940 445 385 800 380 315 670 315 260

0.90 225 985 465 445 840 395 355 710 335 290 600 285 245

NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.

NOTE − Air volumes based on bottom return air. Actual air volume may vary on side return air applications.

G60UH−36C−110 PERFORMANCE

External Static

Air Volume / Watts at Various Blower Speeds

External

Static

Pressure

High Medium−High Medium−Low Low

in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts

0.00 0 1555 735 715 1335 630 575 1085 510 460 925 435 365

0.05 12 1540 725 705 1330 630 555 1080 510 450 920 435 360

0.10 25 1525 720 690 1320 625 545 1075 505 440 915 430 355

0.15 37 1510 715 680 1310 620 535 1070 505 430 910 430 350

0.20 50 1490 705 670 1295 610 525 1065 505 420 900 425 340

0.25 62 1465 690 655 1280 605 510 1060 500 415 890 420 335

0.30 75 1440 680 645 1260 595 495 1050 495 405 880 415 330

0.40 100 1385 655 615 1230 580 485 1030 485 390 865 410 320

0.50 125 1320 625 590 1190 560 460 995 470 375 835 395 300

0.60 150 1260 595 570 1135 535 430 960 455 355 815 385 295

0.70 175 1190 560 545 1075 505 410 915 430 345 775 365 285

0.80 200 1090 515 515 970 460 385 860 405 325 760 360 280

0.90 225 975 460 485 880 415 360 790 375 305 705 335 275

NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.

NOTE − Air volumes based on bottom return air. Actual air volume may vary on side return air applications.

G60UH−48B−070 PERFORMANCE

External Static

Air Volume / Watts at Different Blower Speeds

External

Static

Pressure

High Medium−High Medium−Low Low

in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts

.00 0 2080 980 846 1810 855 764 1535 725 634 1295 610 519

.10 25 2030 955 810 1790 845 714 1520 715 600 1285 605 492

.20 50 1955 920 767 1760 830 675 1515 715 566 1275 600 477

.30 75 1885 890 732 1710 805 640 1505 710 555 1265 595 459

.40 100 1820 860 699 1670 790 611 1470 695 525 1255 590 443

.50 125 1740 820 664 1600 755 575 1420 670 496 1215 575 414

.60 150 1635 770 624 1530 720 544 1350 635 464 1175 555 400

.70 175 1545 730 597 1420 670 501 1270 600 432 1080 510 368

.80 200 1400 660 554 1295 610 462 1135 535 392 990 465 343

.90 225 1250 590 512 1125 530 419 1050 495 372 875 410 310

NOTES − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
