BLOWER DATA Cont.
G60UH−48B−090 PERFORMANCE
External Static
Air Volume / Watts at Various Blower Speeds
External
Static
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 1970 930 790 1810 855 735 1585 750 670 1340 630 565
0.05 12 1940 915 780 1785 840 715 1580 745 650 1335 630 555
0.10 25 1915 905 765 1760 830 695 1570 740 630 1325 625 540
0.15 37 1880 885 745 1730 815 660 1560 735 615 1325 625 530
0.20 50 1840 870 730 1700 800 620 1545 730 600 1320 625 520
0.25 62 1805 850 715 1670 790 625 1520 715 585 1310 620 510
0.30 75 1765 835 695 1640 775 625 1490 705 565 1295 610 500
0.40 100 1695 800 670 1570 740 595 1440 680 540 1260 595 480
0.50 125 1600 755 635 1490 705 560 1360 640 505 1195 565 450
0.60 150 1505 710 600 1400 660 530 1285 605 480 1140 540 425
0.70 175 1395 660 565 1265 595 485 1170 550 440 990 465 380
0.80 200 1250 590 520 1100 520 445 975 460 390 905 425 355
0.90 225 1005 475 460 870 410 385 900 425 365 810 380 325
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
NOTE − Air volumes based on bottom return air. Actual air volume may vary on side return air applications.
G60UH−48C−110 PERFORMANCE
External Static
Air Volume / Watts at Various Blower Speeds
External
Static
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 2015 950 895 1620 765 780 1340 630 640 1150 545 525
0.05 12 1990 940 870 1615 760 760 1340 630 640 1150 545 525
0.10 25 1965 925 850 1610 760 745 1340 630 640 1150 545 525
0.15 37 1930 910 825 1605 755 725 1335 630 630 1150 545 525
0.20 50 1895 895 805 1600 755 710 1335 630 615 1150 545 525
0.25 62 1860 880 785 1590 750 695 1330 630 605 1150 545 520
0.30 75 1820 860 765 1580 745 675 1330 630 590 1145 540 515
0.40 100 1740 820 725 1530 720 635 1320 625 560 1140 540 490
0.50 125 1665 785 695 1475 695 600 1285 605 525 1120 530 470
0.60 150 1575 745 650 1405 665 555 1230 580 490 1075 505 445
0.70 175 1475 695 610 1310 620 515 1165 550 470 1015 480 415
0.80 200 1350 635 560 1210 570 485 1080 510 430 930 440 380
0.90 225 1210 570 520 1070 505 430 870 410 365 740 350 325
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
NOTE − Air volumes based on bottom return air. Actual air volume may vary on side return air applications.
G60UH−60C−110 with 3/4 hp PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Re-
turn Air from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Various Blower Speeds
External
Static
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 2450 1155 1220 2300 1085 1060 2056 970 905 1725 815 735
0.05 12 2410 1135 1205 2265 1070 1045 2040 965 895 1715 810 725
0.10 25 2370 1120 1195 2230 1050 1030 2020 955 890 1710 810 720
0.15 37 2325 1095 1175 2200 1040 1015 1995 940 875 1700 800 715
0.20 50 2280 1075 1165 2170 1025 1005 1975 935 870 1695 800 710
0.25 62 2245 1060 1150 2130 1005 990 1950 920 855 1680 795 705
0.30 75 2205 1040 1135 2095 990 975 1925 910 845 1665 785 700
0.40 100 2115 995 1105 2010 950 940 1860 875 820 1625 770 685
0.50 125 2025 955 1060 1945 920 920 1810 855 805 1605 755 675
0.60 150 1910 900 1015 1850 875 885 1715 810 780 1540 730 670
0.70 175 1835 865 1005 1775 840 865 1655 780 765 1495 705 655
0.80 200 1745 825 975 1655 780 835 1540 725 730 1400 660 635
0.90 225 1610 760 945 1540 725 805 1475 695 715 1310 620 615
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
