BLOWER DATA Cont.
G60UH−60C−110 with 1 hp PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Re-
turn Air from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Different Blower Speeds
External
Static
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2555 1205 1378 2300 1085 1027 1985 935 863 1655 780 678
.10 25 2490 1175 1354 2265 1070 1002 1980 935 839 1640 775 667
.20 50 2420 1140 1330 2225 1050 980 1975 930 832 1635 770 660
.30 75 2355 1110 1300 2175 1025 957 1945 915 810 1625 765 653
.40 100 2275 1075 1265 2115 1000 934 1915 905 785 1620 765 639
.50 125 2175 1025 1229 2040 960 903 1860 875 762 1595 750 623
.60 150 2085 985 1199 1965 925 873 1800 850 733 1565 740 608
.70 175 1990 940 1140 1870 880 843 1730 815 714 1525 720 590
.80 200 1890 890 1105 1770 835 807 1630 770 676 1455 685 567
.90 225 1760 830 1067 1655 780 777 1535 725 649 1370 645 541
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G60UH−60C−110 with 1 hp PERFORMANCE − Single Side Return Air − Air volumes in bold require field fabricated transition
to accommodate 20 x 25 x 1 in. (508 x 635 x25 mm) cleanable air filter in order to maintain proper air velocity.
External Static
Air Volume / Watts at Different Blower Speeds
External
Static
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2385 1125 1296 2185 1030 981 1915 905 836 1650 780 686
.10 25 2330 1100 1274 2150 1015 961 1900 895 815 1635 770 677
.20 50 2255 1065 1234 2095 990 930 1885 890 794 1625 765 664
.30 75 2190 1035 1207 2035 960 902 1855 875 769 1620 765 651
.40 100 2115 1000 1179 1970 930 876 1820 860 751 1605 755 639
.50 125 2055 970 1156 1905 900 853 1760 830 725 1575 745 622
.60 150 1985 935 1141 1830 865 827 1705 805 704 1525 720 602
.70 175 1910 900 1119 1745 825 797 1635 770 680 1475 695 582
.80 200 1810 855 1088 1650 780 772 1560 735 659 1430 675 571
.90 225 1715 810 1058 1570 740 751 1485 700 638 1355 640 549
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G60UH−60D−135 with 1 hp PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Re-
turn Air from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Different Blower Speeds
External
Static
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2715 1280 1407 2255 1065 1070 1910 900 850 1660 785 674
.10 25 2640 1245 1403 2250 1060 1030 1900 895 834 1645 775 668
.20 50 2540 1200 1355 2245 1060 1006 1890 890 821 1630 770 665
.30 75 2480 1170 1319 2200 1040 975 1890 890 781 1625 765 656
.40 100 2390 1125 1282 2155 1015 940 1885 890 775 1615 760 642
.50 125 2320 1095 1251 2085 985 904 1860 875 758 1605 755 631
.60 150 2205 1040 1210 2020 955 876 1815 855 731 1595 750 611
.70 175 2080 980 1161 1935 915 839 1760 830 707 1545 730 588
.80 200 2010 950 1122 1855 875 810 1690 795 679 1495 705 568
.90 225 1880 885 1071 1755 830 781 1585 745 646 1430 675 545
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
