29
Panel Setup:
9 Heating staging jumper
Circle one: 85 90 100 110
120 130
Recommended 120 deg-F
9 Zone 1 PIAB 140F DAS
jumper in place
Circle one: Yes No
See “1.10.4. Zone 1 PIAB
Jumpers – 140ºF DAS” on
page 10.
9 Cooling staging jumper Circle one: 50 55 60
Select desired discharge air
temp during cooling
9 Cont. Air Reduction jumper Circle one: 0 25 50 75
Percentageairowreduction
for continuous fan operation
9 Heating Air Reduction
jumper
Circle one: 0 20 40
Percentageairowreduction
for heating mode
9 SystemConguration
jumpers
Circle one: HP GAS Set to GAS
9 Stages Circle one: 2COOL 1COOL
Set to match condenser, 1 or
2 stage
9 Stages Circle one: 2HP 1HP
Ignored for gas heat, non-heat
pump application
9 E-HEAT Stages Circle one: DF 1 2 3
Ignored for gas heat, non-heat
pump application
9 Desired total system CFM
with all zones calling:
Total system CFM per tables: Minimum CFM:
9 Zone 1 Name: Desired CFM: PIAB Setting: Actual CFM:
9 Zone 2 Name: Desired CFM: PIAB Setting: Actual CFM:
9 Zone 3 Name: Desired CFM: PIAB Setting: Actual CFM:
9 Zone 4 Name: Desired CFM: PIAB Setting: Actual CFM:
Field Wiring Checklist
√ Indoor Unit Wiring Completed:
DS” on Harmony III to “DS” on indoor unit connected
”C” on indoor unit connected to Harmony III zoning system transformer “C”,
No connection to “Y1” or “Y2” on indoor unit.
√ Outdoor Unit Wiring Completed
√ Thermostat and damper wiring completed
√ Discharge Sensor wired to Harmony III zoning system
3.3.3.2. SL280V, SL280NV, EL296V and SL297NV — Cooling/Heating (Non-
Heat Pump)
Job Name:
Indoor Unit Model:
Outdoor Unit Model:
Indoor Unit Setup:
9 Cut on-board link W914 DEHUM OR HARMONY (R to DS) on furnace IFC control (if not cut,
fuse will blow in Harmony III zoning system control board)
9 DIP switch settings (ON or OFF):
DIPSwitch ON or OFF Condition
1 OFF
DIP switch 1 – leave at factory setting – ignored by Harmony III
zoning system
2 OFF
DIP switch 2 – leave at factory setting – ignored by Harmony III
zoning system
3 ON
DIP switches 3 and 4 – Blower Off Delay Switch Settings, set DIP
switches 3 and 4 to ON (180 seconds)
4 ON
DIP switches 4 and 5 determine heating blower “off” delay –
recommended 180 seconds
5 OFF
DIP switches 5 and 6 - Cooling Mode Blower Speed, set DIP
switches 5 and 6 to OFF (High - Factory)
6 OFF
7 OFF
DIP Switches 7 and 8 - Cooling Blower Speed Adjustment, set DIP
switches 7 and 8 to OFF (Factory Default)
8 OFF
9 OFF
DIP Switches 9 and 10 - Cooling Mode Blower Speed Ramping, set
DIP switches 9 and 10 to OFF (A - Factory)
10 OFF
11 OFF
DIP Switches 11, 12 and 13 - Heating Mode Blower Speed, set DIP
switches 11, 12 and 13 to OFF (Factory Default)
12 OFF
13 OFF
14 OFF DIP Switches 14 and 15 - Continuous Blower Speed, set DIP
switches 14 and 15 to OFF (38% of High Cool Speed - Factory
Default)
15 OFF
To Next Page
