Lennox HP29 Series User Manual

Page 2
SPECIFICATIONS
Model No. HP29−090−2 HP29−120−2
Nominal Size − Tons (kW) 7.5 (26.4) 10 (35.2)
Liquid line (o.d.)  in. (mm) connection (sweat) 5/8 (15.9)
Vapor line (o.d.)  in. (mm) connection (sweat) 1−3/8 (34.9)
Net face area 
Outer coil 21.80 (2.03) (2) 29.34 (2.73)
Outdoor
Net
face
area
sq. ft. (m
2
)
Inner coil 20.94 (1.95) − − − −
Outdoor
Coil
Tube diameter  in. (mm) & no. of rows 3/8 (9.5) − 2
Fins per inch (m) 20 (787)
Diameter  in. (mm) & no. of blades (1) 24 (610) − 4 (2) 24 (610) − 3
Outdoor
Motor hp (W) (1) 1/2 (373) (2) 1/3 (249)
Outdoor
Coil
F()
Cfm (L/s) total air volume 5300 (2500) 8200 (3870)
Fan(s)
Rpm 1075 1100
Motor Input − Watts 350 700
Refrigerant charge dry air
Shipping weight  lbs. (kg) 1 package 506 (230) 604 (284)
OPTIONAL ACCESSORIES – Must Be Ordered Extra
Hail Guards 83K37 79K91
SPECIFICATIONS
General
D
Model No. HP29− 090−3 HP29−120−3
G
Data
Nominal Size − Tons (kW) 7.5 (26.4) 10 (35.2)
Connections
(t)
Liquid line (o.d.) − in. (mm) connection 5/8 (15.9) 5/8 (15.9)
(sweat)
Vapor line (o.d.) − in. (mm) connection 1−3/8 (34.9) 1−3/8 (34.9)
Refrigerant dry air holding charge dry air holding charge
Outdoor
Cil
Net face area − sq. ft. (m
2
) Outer coil 30.0 (2.79) (2) 29.34 (2.73)
Coil
Inner coil 28.94 (2.69) − − −
Tube diameter − in. (mm) & no. of rows 3/8 (9.5) − 2 3/8 (9.5) − 2
Fins per inch (m) 20 (787) 20 (787)
Outdoor
Cil
Diameter − in. (mm) & no. of blades (1) 24 (610) − 4 (2) 24 (610) − 3
Coil
Fan
(
s
)
Motor hp (W) (1) 3/4 (560) (2) 1/3 (249)
Fan(s)
cfm (L/s) total air volume 5400 (2550) 8200 (3870)
Rpm 1075 1100
Motor Input − Watts 600 700
Shipping lbs. (kg) 1 package 485 (220) 604 (284)
OPTIONAL ACCESSORIES – Must Be Ordered Extra
Hail Guards 29M45 79K91
