ELECTRICAL DATA
Model No. HP29−090−2 HP29−120−2
Line voltage data 60 hz − 3 phase 208/230v 460v 575v 208/230v 460v 575v
Rec. max. fuse or circuit breaker size (amps) 60 30 25 80 40 25
{Minimum circuit ampacity 39 20 15 53 25 18
Rated load amps 28.8 14.7 10.8 37.8 17.2 12.4
Compressor (1)
Locked rotor amps 195 95 80 239 125 80
Full load amps (total) 3 1.5 1.2 2.4 (4.8) 1.3 (2.6) 1 (2)
FanMotor (1 phase)
Locked rotor amps (total) 6 3 2.9 4.7 (9.4) 2.4 (4.8) 1.9 (3.8)
{Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
NOTE Extremes of operating range are plus and minus 10% of line voltage.
HACR type (under 100 amps). U.S. only.
ELECTRICAL DATA
General
Model No. HP29−090−3 HP29−120−3
Data
Line voltage data − 60 hz − 3 phase 208/230v 460v 575v 208/230v 460v 575v
Rec. max. fuse or circuit breaker size (amps) 60 35 25 80 40 25
{Minimum circuit ampacity 40 21 16 53 25 18
Compressor (1) Rated load amps 28.8 14.7 10.8 37.8 17.2 12.4
Locked rotor amps 195 95 80 239 125 80
Outdoor Coil
Full load amps (total) 3.7 1.9 1.6 2.4 (4.8) 1.3 (2.6) 1 (2)
Locked rotor amps (total) 7.3 3.7 3.4 4.7 (9.4) 2.4 (4.8) 1.9 (3.8)
{Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
NOTE Extremes of operating range are plus and minus 10% of line voltage.
HACR type (under 100 amps). U.S. only.
