SPECIFICATIONS three phase
General
Dt
Model No. HPXA12−036 HPXA12−048 HPXA12−060
Data
Nominal Tonnage (kW) 3 (10.6) 4 (14.1) 5 (17.6)
Connections
(sweat)
Liquid line o.d. − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
(sweat)
Vapor line o.d. − in. (mm) 7/8 (22.2) 7/8 (22.2) 1−1/8 (28.6)
1
Refrigerant (R410A) furnished 8 lbs. 15 oz. (4.1 kg) 11 lbs. 5 oz. (5.1 kg) 11 lbs. 3 oz. (5.1 kg)
Outdoor
Cil
Diameter − in. (mm) & no. of blades 18 (457) − 4 22 (559) − 4 22 (559) − 4
Coil
Fan
Motor hp (W) 1/6 (124) 1/3 (249) 1/3 (249)
Fan
Cfm (L/s) 2450 (1155) 3890 (1835) 3890 (1835)
Rpm 1100 1085 1085
Watts 200 375 375
Outdoor
Cil
Net face area
2
Outer coil 15.21 (1.41) 21.11 (1.96) 21.11 (1.96)
Coil
Net
face
area
sq. ft. (m
2
)
Inner coil 14.50 (1.35) 20.31 (1.89) 20.31 (1.89)
Tube diameter − in. (mm) & no. of rows 5/16 (8) − 2 5/16 (8) − 2 5/16 (8) − 2
Fins per inch (m) 18 (709) 22 (860) 22 (860)
Shipping Data 1 package − lbs. (kg) 181 (82) 244 (111) 244 (111)
ELECTRICAL DATA
Model No. HPXA12−036
−233
HPXA12−036
−463
HPXA12−048
−233
HPXA12−048
−463
HPXA12−060
−233
HPXA12−060
−463
Line voltage data − 60 hz − 3 phase 208/230V 460V 208/230V 460V 208/230V 460V
2
Maximum overcurrent protection (amps) 25 10 35 15 40 20
3
Minimum circuit ampacity 15.4 6.9 21.9 9.8 24.5 12.2
Compressor
Rated load amps
11.5 5.1 16 7.1 18.1 9
p
Locked Rotor amps 77 35 91 46 137 62
Power Factor .98 .98 .99 .99 .99 .99
Outdoor Coil
FMt
Full load amps
1 .55 1.9 .9 1.9 .9
Fan Motor
Locked Rotor Amps 2.3 1 4.1 2.1 4.1 2.1
OPTIONAL ACCESSORIES − MUST BE ORDERED EXTRA
Compressor Low Ambient Cut−Off 45F08 45F08 45F08
Compressor Sound Cover 69J03 69J03 69J03
Compressor Crankcase Heater 67K90 67K89 Factory Installed Factory Installed
Freezestat
3/8 in. tubing 93G35 93G35 93G35
1/2 in. tubing 39H29 39H29 39H29
5/8 in. tubing 50A93 50A93 50A93
Hail Guards 17L73 17L74 17L74
Low Ambient Kit 54M89 54M89 54M89
Mild Weather Kit 33M07 33M07 33M07
Monitor Kit − Service Light 76F53 76F53 76F53
Outdoor
Thermostat
Thermostat 56A87 56A87 56A87
Thermostat
Kit
Mounting Box − US 31461 31461 31461
Kit
Canada 33A09 33A09 33A09
Mounting
Base
Model (Catalog) No. MB2-S (69J06) MB2-L (69J07) MB2-L (69J07)
g
Base
Net Weight 6 lbs. (3 kg) 15 lbs. (7 kg) 15 lbs. (7 kg)
Refrigerant
Line Set
15 ft. (4.6 m) length L15−65−15 L15−65−15 Field Fabricate
g
Line Set
30 ft. (9 m) length L15−65−30 L15−65−30 Field Fabricate
40 ft. (12 m) length L15−65−40 L15−65−40 Field Fabricate
50 ft. (15 m) length L15−65−50 L15−65−50 Field Fabricate
Unit Stand-Off Kit 94J45 94J45 94J45
NOTE − Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Refrigerant charge is sufficient for 15 ft. (4.6 m) length line set.
2
HACR tyoe circuit breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
