INNOV@ ECFAN DHR -AGU-0912-E • 13 •
The following steps should be carried out to ensure proper installation:
· Apply a anti-vibration rubber lining between the unit and the bottom.
· Position the unit on the floor / floorstand (base frame).
The recommended sizes for the power cables and emergency line are shown in the related electrical drawings.
DX version
DHADR0201 - DHAUR0201
DHADR0251 - DHAUR0251
1010 750 795 10 1998
DHADR0281 - DHAUR0281
DHADR0311 - DHAUR0311
1270 750 795 10 1998
DHADR0401 - DHAUR0401
DHADR0272 - DHAUR0272
DHADR0302 - DHAUR0302
DHADR0362 - DHAUR0362
DHADR0422 - DHAUR0422
DHADR0452 - DHAUR0452
1760 750 795 10 1998
DHADR0532 - DHAUR0532
DHADR0592 - DHAUR0592
2020 750 795 10 1998
DHADR0602 - DHAUR0602
DHADR0692 - DHAUR0692
DHADR0762 - DHAUR0762
2510 750 795 10 1998
DHADR1002 – DHAUR1002
2510 750 950 10 1998
DHADR1204 – DHAUR1204
3180 750 950 10 1998
Model A (mm) B (mm) C (mm) D (mm) E (mm)
