OPTIONS / ACCESSORIES
Item
Model
Number
Catalog
Number
Unit Model Number
036 048 060 072 074
COOLING SYSTEM
Condensate Drain Trap PVC - C1TRAP20AD2 76W26 OX OX OX OX OX
Copper - C1TRAP10AD2 76W27 OX OX OX OX OX
Conventional Fin/Tube Condenser Coil (replaces Environ™ Coil System) Factory O O O O O
Drain Pan Overow Switch E1SNSR71AD1 68W88 OX OX OX OX OX
Efciency Standard Factory O O O
High Factory O O O O O
Service Valves (not for Environ™ Coil System or Humiditrol® Dehumidication Option) Factory O O O O O
BLOWER - SUPPLY AIR
Motors Direct Drive - 0.50 hp Factory O
Direct Drive - 0.75 hp Factory O
Direct Drive - 1 hp Factory O
Belt Drive - 0.75 hp (2 Speed) Factory O O
Belt Drive - 1 hp (2 Speed) Factory O O O
Belt Drive - 2 hp (2 Speed) Factory O O O
Belt Drive - 1 hp Standard Efciency Factory O
Belt Drive - 2 hp Standard Efciency Factory O
Drive Kits
See Blower Data Tables for
selection
Kit A01 - T1DRKT001-1 - 673-1010 rpm Factory O
Kit A02 - T1DRKT002-1 - 745-1117 rpm Factory O
Kit A03 - T1DRKT003-1 - 833-1250 rpm Factory O
Kit A05 - T1DRKT005-1 - 897-1346 rpm Factory O
Kit A06 - T1DRKT006-1 - 1071-1429 rpm Factory O
Kit A07 - T1DRKT007-1 - 1212-1548 rpm Factory O
Kit AA01 - T1DRKT001AP1 - 522-784 rpm Factory O O
Kit AA02 - T1DRKT002AP1 - 632-875 rpm Factory O O
Kit AA03 - T1DRKT003AP1 - 798-1105 rpm Factory
O O
Blower Belt Auto-Tensioner Factory O O O O O
ELECTRIC HEAT
7.5 kW 208/230V-1ph - E1EH0075AN1P
46W28 OX OX OX
208/230V-3ph - E1EH0075AN1Y 46W31 OX OX OX OX OX
460V-3ph - E1EH0075AN1G 46W35 OX OX OX OX OX
575V-3ph - E1EH0075AN1J 46W39 OX OX OX OX OX
15 kW 208/230V-1ph - E1EH0150AN1P 46W29 OX OX OX
208/230V-3ph - E1EH0150AN1Y 46W32 OX OX OX OX OX
460V-3ph - E1EH0150AN1G 46W36 OX OX OX OX OX
575V-3ph - E1EH0150AN1J 46W40 OX OX OX OX OX
22.5 kW 208/230V-1ph - E1EH0225N1P 46W30 OX
208/230V-3ph -- E1EH0225N1Y
46W33 OX OX OX
460V-3ph - E1EH0225N1G 46W37 OX OX OX
575V-3ph - E1EH0225N1J 46W41 OX OX OX
30 kW 208/230V-3ph - E1EH0300N-1Y 46W34 OX OX
460V-3ph -- E1EH0300N-1G 46W38 OX OX
575V-3ph - E1EH0300N-1J 46W42 OX OX
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed
