Page 35
LCH PLUMBING and S49 FREEZESTAT LOCATION
FIGURE 6
EVAPORATOR COIL
CONDENSER COIL
DRIER
EXPANSION VALVE
COMPRESSOR
INDOOR BLOWER SECTION
HEAT SECTION
CONTROL AND
COMPONENTS
SECTION
PROCESS TUBE
(used for charging)
RETURN AIR
SECTION
S49 S49 S49
036 048 060, 072, 074
