SPECIFICATIONS
General Data Nominal Tonnage 13 Ton 13 Ton 13 Ton
Model Number LGH156H4B LGH156H4V LGH156H4M
High High High
Blower Type CAV
(Constant Air Volume)
VAV
(Variable Air Volume)
MSAV
®
(Multi-Stage Air Volume)
Cooling
Performance
Gross Cooling Capacity - Btuh 154,000 152,000 154,000
1
Net Cooling Capacity - Btuh 150,000 148,000 150,000
AHRI Rated Air Flow - cfm 5000 4600 5000
Total Unit Power - kW 12.5 12.3 12.5
1
EER (Btuh/Watt) 12.0 12.0 12.0
2
IEER (Btuh/Watt) 13.2 14.5 14.1
Refrigerant
Charge
Refrigerant Type R-410A R-410A R-410A
Environ™ Coil System Circuit 1 5 lbs. 12 oz. 5 lbs. 0 oz. 5 lbs. 12 oz.
Circuit 2 5 lbs. 4 oz. 5 lbs. 8 oz. 5 lbs. 4 oz.
Circuit 3 5 lbs. 10 oz. 5 lbs. 0 oz. 5 lbs. 10 oz.
Environ™ Coil System
with Humiditrol
®
Circuit 1 5 lbs. 14 oz. - - - 5 lbs. 14 oz.
Circuit 2 5 lbs. 8 oz. - - - 5 lbs. 8 oz.
Circuit 3 5 lbs. 12 oz. - - - 5 lbs. 12 oz.
Conventional Fin/Tube
Coil Option
Circuit 1 10 lbs. 0 oz. - - - 10 lbs. 0 oz.
Circuit 2 10 lbs. 0 oz. - - - 10 lbs. 0 oz.
Circuit 3 - - -
Conventional Fin/Tube
With Humiditrol
®
Circuit 1 12 lbs. 0 oz. - - - 12 lbs. 0 oz.
Circuit 2 12 lbs. 0 oz. - - - 12 lbs. 0 oz.
Circuit 3 - - -
Gas Heating Options Available See page 33
Compressor Type (number) Scroll (3) Scroll (3) Scroll (3)
Outdoor Coils
Environ™
(Fin/Tube)
Net face area (total) - sq. ft. 41.4 41.4 41.4
Number of rows 1 (2) 1 (2) 1 (2)
Fins per inch 23 (20) 23 (20) 23 (20)
Outdoor Coil
Fans
Motor - (No.) horsepower (3) 1/3 (3) 1/3 (3) 1/3
Motor rpm 1075 1075 1075
Total Motor watts 1100 1100 1100
Diameter - (No.) in. (3) 24 (3) 24 (3) 24
Number of blades 3 3 3
Total Air volume - cfm 12,000 12,000 12,000
Indoor Coils Net face area (total) - sq. ft. 21.4 21.4 21.4
Tube diameter - in. 3/8 3/8 3/8
Number of rows 3 3 3
Fins per inch 14 14 14
Drain connection - No. and size (1) 1 in. FPT (1) 1 in. FPT (1) 1 in. FPT
Expansion device type Balance port TXV, removable head
3
Indoor
Blower
and
Drive
Selection
Nominal motor output 2 hp, 3 hp, 5 hp
Max. usable motor output (US) 2.3 hp, 3.45 hp, 5.75 hp
Motor - Drive kit number 2 hp
Kit 1 535-725 rpm
Kit 2
Kit 1 535-725 rpm
Kit 2
Kit 3 685-856 rpm
Kit 4 850-1045 rpm
5 hp
Kit 3 - 685-856 rpm
Kit 4 850-1045 rpm
Kit 5
Blower wheel nominal D x W - in. (2) 15 x 15 in. (2) 15 x 15 in. (2) 15 x 15 in.
Filters Fiberglass, disposable
Number and size - in. (6) 24 x 24 x 2
Electrical characteristics 208/230V, 460V or 575V - 60 hertz - 3 phase
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1
2
3
Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within
the service factor limitations outlined on the motor nameplate.
NOTE – Units equipped with MSAV
®
(Multi-Stage Air Volume) option are limited to a motor service factor of 1.0.
