Lennox LGH240H

Page 80
EVAPORATOR
COIL
STAGE 1
CONDENSER
COILS
156, 180H, & 210 REFRIGERANT CIRCUITS
STAGE 2
CONDENSER
COILS
STAGE 1
EVAPORATOR
COIL
STAGE 2
EVAPORATOR
COIL
156, 180 VAV ONLY
EVAPORATOR COIL
(not to scale)
STAGE 1
CIRCUIT 1
STAGE 3
CIRCUIT 1, 2, & 3
STAGE 2
CIRCUIT 1 & 2
INTERTWINED
STAGE 4
CIRCUITS
1, 2, 3, & 4
INTERTWINED
EVAPORATOR
COIL
STAGE 1
CONDENSER
COIL
240H & 300S REFRIGERANT CIRCUITS
STAGE 2
CONDENSER COIL
STAGE 1
EVAPORATOR
COIL
STAGE 2
EVAPORATOR
COIL
240 VAV ONLY
EVAPORATOR
COIL
(not to scale)
STAGE 1
CIRCUIT 1
STAGE 2
CIRCUITS 1 & 2
INTERTWINED
STAGE 3
CIRCUITS 1, 2, & 3
INTERTWINED
FIGURE 26
