UNIT
CONTROLLER
EVAPORATOR
COIL
CONDENSER
FANS
CONDENSER
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
IGNITION
CONTROL
REHEAT COIL
(OPTIONAL)
WIRELESS
BOARD
WIFI
ANTENNA
PARTS ARRANGEMENT
FIGURE 1
CONTROL BOX PARTS ARRANGEMENT
W4
A55
K65
K10
K68
T3
TB13
K1
K2
C1 C2
S117
T1
T43
FIGURE 2
