LAOAD(M) MOTORIZED OUTDOOR AIR DAMPER
LOWER PANEL
COVER PANEL
MOTORIZED
DAMPER
HORIZONTAL
RETURN AIR
OPENING
HORIZONTAL
SUPPLY AIR
OPENING
COMPRESSOR
SECTION
FIGURE 29
LOWER PANEL
MANUAL OUTDOOR AIR DAMPER
COVER PANEL
HORIZONTAL
RETURN AIR
OPENING
HORIZONTAL
SUPPLY AIR
OPENING
COMPRESSOR
SECTION
MANUAL DAMPER
FIGURE 30
