Page 27
LHT/LDT024, 036, 048, 060
FIGURE 18
YELLOW
RT46
CLAMP THERMISTOR
TO BARE COPPER.
DETAILS NOT TO SCALE
22J06
LHT/LDT024, 036, 048
INDOOR COIL
RT46
