LHT/LDT024, 036, 048, 060
FIGURE 20
LHT/LDT048
OUTDOOR COIL
RT48
CLAMP THERMISTOR
TO BARE COPPER.
DETAILS NOT TO SCALE
YELLOW
RT48
22J08
