Page 30
LHT/LDT024, 036, 048, 060
FIGURE 21
YELLOW
RT46
CLAMP THERMISTOR
TO BARE COPPER.
DETAILS NOT TO SCALE
LHT/LDT060
INDOOR COIL
RT46
22J06
