Page 31
LHT/LDT024, 036, 048, 060
FIGURE 22
CLAMP THERMISTOR
TO BARE COPPER.
DETAILS NOT TO SCALE
LHT/LDT060
OUTDOOR COIL
RT48
YELLOW
RT48
22J08
